Thank you for purchasing a Taylor® infrared thermometer.Please read thisinstruction manual carefully before use.
Keeptheseinstructionshandyforfuturereference.
Thethermometerisanoncontactinfraredthermometer.SimplyaimthethermometeratthetargetandpresstheScan
key todisplaythesurfacetemperature.
Temperature Reading Operation
Press the ‘Scan key’ to take a temperature
reading. The unit will display the
temperature of the target for 10 seconds
then turn off automatically.
CAUTION!
1. WHEN DEVICE IS IN USE, DO NOT
LOOK DIRECTLY INTO THE LASER
BEAM–PERMANENT EYE DAMAGE
MAY RESULT.
2. USE EXTREME CAUTION WHEN
OPERATING THE LASER.
3. NEVER POINT THE DEVICE TOWARDS
ANYONE’S EYES.
4. KEEP OUT OF REACH OF ALL CHILDREN.
Continuous Temperature Reading Operation
1.Press andholddown the “Scan”key.
2. Theunitwilldisplaycontinuallyupdatedrealtime temperature readingswhilethe “Scan” keyishelddown.Whenthe
keyisreleased,thelasttemperaturewilldisplayfor10seconds,and thentheunitwillturnoffautomatically.
HACCP CHECK
The HACCP CHECK” feature is incorporated in our thermometer
temperaturetographicallyindicatecriticaltemperaturezone.Theiconsand
LED indicatorslocated abovethedisplayindicate if a foodproductisina
safeorunsafeHACCP DangerZone”temperature.ThegreenandredLED
lightwillalwaysbelitbefore the power isturned off.
A Green LED light with a ” ” icon indicates a safe cool or frozen
condition below 40
o
F (4
o
C), while a” ” icon indicates a safe holding
temperatureabove 140
o
F (60
o
C).
When the temperature is between 40
o
F (4
o
C) and 140
o
F (60
o
C), the red
LEDwith a” ”iconwillappearandindicatethatthetemperatureisfallenwithintheHACCP“DangerZone”from40
o
to 140
o
F (4~60
o
C).
°C OR °F MODE
Tochangethethermometerfrom°C’to‘°F’orfrom°F’to‘°C’,firstturntheinstrumentonbypressingthe‘Scankey’,
thenpressthe Modekey’onetime. The‘°C’ or ‘°F’ symbolwillflash. Pressthe ‘Scankey’ tochangetoscale.
EMISSIVITY RANGE
The infrared thermometer is supplied with a default emissivity of 0.95. The emissivity of the thermometer can be
changed from 0.05(5E) to 1 (100E). Changes should only be carried out by experienced personnel.To change the
emissivity, firstly turn the instrument on by pressing the Scan’ button, then press the ‘Mode’ button two times for
emissivityfunction.The95EwillflashontheLCDscreen,thenpresstheMeas.’buttontoadjusttheemissivityvalue,
pressthe ‘Mode’buttonagaintoexitthesetupscreen.Forinformationrelatingto theemissivityofspecificmaterials,
pleasecontactthenearestretailer.Note:noncontactinfraredthermometersarenotrecommendedforuseinmeasuring
the temperatureofshinyorpolishedmetals.
BAR DISPLAY: The fixed setting range for bar display is 68428°F (20~220°C) and Center=248°F (120°C).
Thebardisplaywillbeupdatedcomplywiththemeasurementreadingchanged.
LCD ERROR MESSAGES
Thethermometerincorporatesvisualdiagnosticmessagesasfollows:
‘Hi’ or ’Lo’ is displayed when the temperature being measured is outside of the range of the
instrument, Hi’ whenhigherthan+662°F (+350°C)and Lo’ whenlowerthan 67°F (–55°C).
‘Er2’isdisplayedwhenthethermometerisexposedtorapidchangesintheambienttemperature.
‘Er3’is displayed whentheambienttemperatureofthe thermometer EXCEEDS 32°F(0°C)OR
+122°F (+50°C). In both cases you should allow plenty of time (minimum 30 minutes) for the
thermometerto stabilize totheworking/roomtemperature.
Forallothererrormessagesitis necessarytoresetthethermometer.Toresetthethermometer,
turn the instrument off, remove the battery and wait for aminimum ofone minute, reinsert the
battery and turn on. If the errormessage remains, pleasecontact CustomerServicefor further
assistance.
BATTERIES
Thethermometerincorporatesvisuallowbatteryindicationasfollows:
‘BatteryOK’:
measurements
arepossible
‘BatteryLow’:batteryneedsto
bereplaced,measurements
arepossible
‘BatteryExhausted’:
measurementsare
notpossible
