Technical Specifications
VoiceLive 3 – Reference manual (2014-03-29) 123
Output Range 0dBFS Line Level: +14dBu
Mic Level: -2dBu
Dynamic Range > 101dB
20Hz to 20kHz
D to A Conversion 24Bit
128 x oversampling bitstream
106dB SNR A-weighted
Headphone
Connector 1/8“ Mini stereo jack
Impedance 50Ohm
Output Range +14dBu max
Guitar Thru
Input Buffered Guitar Input
Connector 1/4“ TRS phone jack
Output Impedance Bal/UnBal 270/540Ohms
Monitor Thru
Signal flow Direct connection to Monitor input
Connector Balanced XLR
Control
USB USB A, Mini-B
MIDI In/Out 5 Pin DIN
Pedal 1/4“ TRS phone jack
Mic Control Available with TC-Helicon MP-75 Microphone or Sennheiser e 835 fx mic
Details
Power
External Power Supply Mains Voltage 100 to 240 VAC
50 to 60 Hz (auto-select)
Power Consumption < 14 W
Safety
EMC – Complies with EN 55103-1:2009, EN 55103-2:2009, FCC CFR 47 Part 15B and ICES-003:2004 4th Ed
Safety – certified to IEC 65, EN 60065, UL6500 and CSA IEC 65, EN 60065, UL6500 and CSA
Operating Requirements
Operating Temperature 32° F to 122° F / 0° C to 50° C
Storage Temperature -22° F to 167° F / -30° C to 70° C
Humidity Max. 90 % non-condensing
