Diagrams
On the following pages, you will see some con-
nection diagrams. We have set things up to give
you clear and concise representations of what
goes where.
There are a few things we would like you to keep
in mind as you look at the diagrams:
1. Inputs to VoiceLive3 will be to the left of the
back panel image.
2. Outputs from VoiceLive3 will be to the right of
the back panel image.
3. There are two boxes on the bottom of each
diagram.
– The VoiceLive3 box shows “what you hear”
from your VoiceLive3 headphone output.
– The P.A. box shows “what you hear” from
the P.A. speakers.
4. We don’t account for other inputs/instruments
when showing “what you hear” from the P.A.,
so you won’t see pictures of drums etc.
5. In a lot of cases, “what you hear” will be the
same for both VoiceLive3 headphone output
and P.A. – but it can also be different.
