Data Sheet

The GenesysTM family of programmable power supplies sets a new standard for flexible, reliable,
AC/DC power systems in OEM, Industrial and Laboratory applications.
Features include:
• High Power Density: 1500W in 1U
• Wide Range Input (85 - 265Vac Continuous, single phase, 47/63Hz)
• Active Power Factor Correction (0.99 typical)
• Output Voltage up to 600V, Current up to 200A
• Built-in RS-232/RS-485 Interface Standard
• Last-Setting Memory
• Global Commands for Serial RS-232/RS-485 Interface
• Front Panel Lock selectable from Front Panel or Software
• High Resolution 16 bit ADCs & DACs
• Reliable Encoders for Voltage and Current Adjustment
• Constant Voltage/Constant Current auto-crossover
• Advanced Parallel reports total current up to four identical units
• Independent Remote ON/OFF and Remote Enable/Disable
• External Analog Programming and Monitoring (user selectable 0-5V & 0-10V)
• Reliable Modular and SMT Design
• 19" Rack Mounted ATE and OEM applications
• Optional Interfaces
Isolated Analog Programming and Monitoring Interface (0-5V/0-10V & 4-20mA)
IEEE 488.2 SCPI (GPIB) Multi-Drop
Compliant LAN Interface
• LabView® and LabWindows® drivers
• Five Year Warranty
Worldwide Safety Agency Approvals; CE Mark for LVD and EMC Regulation
Applications
Genesys™ power supplies have been designed to meet the demands of a wide variety of applications.
Common controls are shared all Genesys™ Series.
Test and Measurement
Last-Setting memory simplifies test design and requires no battery backup.
Built-in RS-232/RS-485 gives maximum system flexibility along with 0-5V and 0-10V, selectable analog programming.
Wide range of available inputs allows testing of many different devices.
Semiconductor Burn-in
Safe-Start may be ENABLED to re-start at Output OFF to protect load.
Wide range input (85-265Vac) with Active Power Factor correction rides through input transients easily.
Component Test
High power density, zero stacking and single wire parallel operation give maximum system flexibility.
Laser Diode
OVP is directly set on Voltage Display, assuring accurate protection settings.
Current Limit Fold Back assures load is protected from current surges.
Heater Supplies
Smooth, reliable encoders enhance front panel control.
Remote analog programming is user selectable 0-5V or 0-10V.
RF Amplifiers and Magnets
Robust design assures stable operation under a wide variety of loads.
High linearity in voltage and current mode.
