ASC80937 RC8T3.1 Manual

ManualsBrandsTeam Associated ManualsCars & TrucksRC8 T3.1 Team 1/8 4WD Off-Road Nitro Truggy Kit

#80937 RC8T3.1 Team Kit

#80938 RC8T3.1e Team Kit

Summary of content (50 pages)

PAGE 1
#80937 RC8T3.1 Team Kit #80938 RC8T3.
PAGE 2
:: Introduction Thank you for purchasing this Team Associated product. This assembly manual contains instructions and tips for building and maintaining your new RC8T3.1/RC8T3.1e Kit. Please take a moment to read through this manual to help familiarize yourself with these steps. We are continually changing and improving our designs; therefore, actual parts may appear slightly different than in the illustrations. New parts will be noted on supplementary sheets located in the appropriate parts bags.
PAGE 3
:: Hardware - 1:1 Scale View Button Head (bhcs) Flat Head (fhcs) Set Screws 2.5x6mm (4675) 2.5x6mm (31520) 3x3mm (25225) 2.5x8mm (31448) 2.5x8mm (31521) 3x6mm (81257) 3x6mm (31541) 2.
PAGE 4
:: Table of Contents 1................... Cover 2................... Introduction 3................... 1:1 Hardware “Fold Out” 4................... Table of Contents 5 - 7..............Differentials Build (Bag 1.1, 1.2) 7 - 8..............Steering / Chassis Build (Bag 2.1, 2.2) 9 - 10...........Front Gearbox Build (Bag 3.1, 3.2) 11 - 12.........Front Uprights Build (Bag 4.1, 4.2) 12 - 14........Rear Gearbox Build (Bag 5.1, 5.2 ) 15 - 16........
PAGE 5
3/18 :: Differential Build (Front and Rear) - Bag 1.1, 1.2 - Step 1 88 #65 ease gr k c bla 81379 Diff Case 81381 Diff Shim 6x8x0.20mm 88 #65 ease gr k c bla 81385 Outdrive O-Ring 5.8x1.9mm 81380 HTC Diff Sun Gear, 20T 81380 Pin 2.5x12mm 91564 8x16x5 Bearing 81012 17mm Outdrive, Front Diff ! 81008 15mm Outdrive, Rear Diff Align pin with groove in sun gear :: Differential Build (Front and Rear) - Bag 1.1, 1.2 - Step 2 81381 x4 Diff Shim 3.5x11x0.
PAGE 6
:: Differential Build (Front and Rear) - Bag 1.1, 1.2 - Step 4 81384 Diff Gasket ! 89208 x4 3x14mm FHCS Racer’s Tip: Use black grease (#6588) to coat the Diff Gasket before installation! 88 #65 ease gr k c a bl Diff Flui d Front Diff Fluid: 10,000cst #5455 Racer’s Tip: Fill diff above the cross pins, below the planet gears as shown. Rear Diff Fluid: 5,000cst #5453 :: Differential Build (Center) - Bag 1.1, 1.2 - Step 5 88 #65 ease gr k c a l b 81379 Diff Case 81381 Diff Shim 6x8x0.
PAGE 7
:: Differential Build (Center) - Bag 1.1, 1.2 - Step 7 #6588 black grease 81385 Outdrive O-Ring 5.8x1.9mm 81389 Plastic Spur Gear, 46T (Electric, shown) 81380 HTC Diff Sun Gear, 20T ! 81380 Pin 2.5x12mm Align pin with groove in sun gear 91564 8x16x5 Bearing 81386 Metal Spur Gear, 46T (Nitro) 81381 Diff Shim 6x8x0.20mm 81012 17mm Outdrive, Center Diff 8 58 ase #6 gre ck la b :: Differential Build (Center) - Bag 1.1, 1.
PAGE 8
:: Steering / Chassis Build - Bag 2.1, 2.2 - Step 2 81084 Servo Saver Tube Racer’s Tip: Use black grease (#6588) to lube the bellcrank halves before installation! 81086 Steering Bellcrank 81086 Steering Bellcrank 81084 x2 Servo Saver Tube Shim 81083 Servo Saver Spring 81084 Servo Saver Tube Spring Nut & O-Ring 1.5mm :: Steering / Chassis Build - Bag 2.1, 2.2 - Step 3 31404 x4 6x10x3mm Bearing 25211 x2 3x10mm BHCS 81086 Steering Bellcrank 89161 x4 5x8x2.
PAGE 9
:: Front Gearbox Build - Bag 3.1, 3.2 - Step 1 91561 x2 6x12x4mm FT Bearing 81015 Gearbox, (Inboard) Racer’s Tip: Use black grease (#6588) to lube the Diff Pinion gear before installation! 8 e s 58 #6 grea k c a l b 81007 Diff Pinion Gear, 10T, V2 96 #15 lock ad 81020 Center Universal, (76mm) 81015 Dust Cap thre 89221 5x4mm Set Screw 4675 2.5x6mm FHCS :: Front Gearbox Build - Bag 3.1, 3.2 - Step 2 NOTE: Install the FRONT Diff! 81381 Diff Shim 13.5x15.8x0.
PAGE 10
:: Front Gearbox Build - Bag 3.1, 3.2 - Step 4 Kit Setup: 25201 x2 3x8mm FHCS 89214 4x12mm FHCS th #1 re 59 ad 6 lo ck 89216 M4 Locknut 81291 RC8B3.1 Arm Mount (A), HRC (not included) 81030 Top Plate 81032 Chassis Brace, Front 81050 x2 Arm Mount Insert, Center 81260 x2 4x14mm BHCS Kit Setup: 81050 x2 Arm Mount Insert, Center 81049 Upper Link Mount :: Front Gearbox Build - Bag 3.1, 3.
PAGE 11
:: Front Uprights Build - Bag 4.1, 4.2 - Step 1 89096 Wheel Hex Pin 81331 CVA Drive Shaft (133mm) 81328 CVA Coupler Pin #6 blac 588 k gr ease 81326 CVA Axle, Steel 81065 Steering Block 81328 CVA Coupler 91566 15x21x4mm Bearing 25225 3x3mm Set Screw ! 81319 Hex Drive Clamp 6 59 ck #1 lo ad e r th Slide the Hex Drive Clamp PAST the groove on the 17mm Hex Drive. Then install onto the Universal Drive Shaft.
PAGE 12
:: Front Uprights Build - Bag 4.1, 4.2 - Step 4 81262 x2 4x10mm FHCS 81113 Front Bumper #159 threa 6 d loc k (not included) 89216 M4 Locknut, Black 81264 x2 4x20mm FHCS 89214 4x12mm FHCS 89214 x2 4x12mm FHCS :: Rear Gearbox Build - Bag 5.1, 5.
PAGE 13
:: Rear Gearbox Build - Bag 5.1, 5.2 - Step 3 Kit Setup: ! 81293 RC8B3.1 Arm Mount (C) HRC Note that each arm is marked with a R for the Right Arm or an L for the Left Arm. 81318 RC8T3 Rear Arm 81050 x2 Arm Mount Insert, Center 81260 x2 4x14mm BHCS 89317 Droop Screw :: Rear Gearbox Build - Bag 5.1, 5.2 - Step 4 Kit Setup: 81318 Rear Arm Shim 81294 RC8B3.1 Arm Mount (D) HRC 81260 x2 4x14mm BHCS 81060 Hinge Pin 81050 x2 Arm Mount Insert, Center :: Rear Gearbox Build - Bag 5.1, 5.
PAGE 14
:: Rear Gearbox Build - Bag 5.1, 5.2 - Step 6 Kit Setup: 1 23 81313 RC8T3 Shock Tower, Rear 45 25203 x2 3x12mm FHCS (not included) 96 #15 lock ad e r th 3 2 1 6 5 4 81323 x2 Body Post, Rear 81196 x2 Shock Bushing #1 59 ead 6 loc k thr 25211 x2 3x10mm BHCS 81049 x2 Upper Link Mount 89225 x2 3x24mm SHCS (not included) :: Rear Gearbox Build - Bag 5.1, 5.
PAGE 15
:: Rear Uprights / Turnbuckles Build - Bag 5.2, 6.1 - Step 1 81331 CVA Drive Shaft (133mm) #6 5 ck 88 gre ase bla 91566 15x21x4mm Bearing 81328 CVA Coupler Pin 81328 CVA Coupler 81326 CVA Axle, Steel 89096 Wheel Hex Pin 81319 Hex Drive, 17mm Offset (Blue) (not included) 6 k 59 loc #1 ad re th 81075 Rear Hub ! Slide the Hex Drive Clamp PAST the groove on the 17mm Hex Drive when installing onto the CVA Drive Shaft.
PAGE 16
:: Rear Uprights / Turnbuckles Build - Bag 5.2, 6.1 - Step 4 81093 Rod End, 4mm, curved 81320 4x85mm Turnbuckle 81093 Rod End, 4mm Steering Turnbuckle 62.0mm (2.44”) RC8T3.1e Electric Kit and RC8T3.1 Nitro Kit If you are building an RC8T3.1e Electric kit, continue on to Center Bulkhead Build below this step. If you are building an RC8T3.1 Nitro kit, go to page 17 to build the Anti-Roll Bars then the Shocks. Then go to page 22 to continue with the RC8T3.1 Nitro build.
PAGE 17
:: Center Bulkhead Build - Bag 7.1, 7.2 - Step 2 (RC8T3.1e) Motor not included! (not included) 89206 x2 4x10mm BHCS 81300 RC8B3e Motor Mount Slide 6 59 ock #1 d l a re th #1596 thread lock Motor pinion not included! 31532 x2 3x8mm BHCS 25224 4x4mm Set Screw :: Anti-Roll Bars Build - Bag 8.1 - Step 1 81150 Anti-Roll Bar Pivot 81150 x2 Anti-Roll Bar Drop Link ! Steering Turnbuckles and upper arms removed for view clarity.
PAGE 18
:: Anti-Roll Bars Build - Bag 8.1 - Step 3 #159 6 threa d lock 96 #15 ock dl a e r th (not included) 25225 x2 3x3mm Set Screw 89203 x2 3x16mm BHCS 31521 x2 2.5x8mm BHCS 81257 x2 3x6mm Set Screw ! Tighten #81257 set screws just enough to still allow the anti-roll bar to move freely. :: Anti-Roll Bars Build - Bag 8.1 - Step 4 25225 x2 3x3mm Set Screw #159 threa 6 d loc k (not included) 31521 x2 2.5x8mm BHCS ! ! Rear Hub Turnbuckles removed for view clarity.
PAGE 19
:: Shocks Build - Bag 9.1 - Step 2 81181 Shock Cap Insert 81179 Bleeder Cap k oc sh id flu ! Front Shock Fluid: 40wt #5423 81184 Seal, Bleeder Cap Leave a gap when installing the shock cap. Rear Shock Fluid: 35wt #5429 ! When installing the shock cap seal, make sure it is correctly seated within the shock cap as shown. :: Shocks Build - Bag 9.1 - Step 3 ! Compress shock shaft fully. Let shock fluid bleed from the bleeder hole.
PAGE 20
:: Radio Tray Build - Bag 10.1, 10.2 - Step 1 81298 x2 RC8B3e Battery Foam ESC not included! 89506 x2 Hook and Loop Battery Strap 81297 RC8B3e Battery Tray :: Radio Tray Build - Bag 10.1, 10.2 - Step 2 ! Install the ESC wire as shown first. Then run the hook and loop straps as shown. :: Radio Tray Build - Bag 10.1, 10.
PAGE 21
25187 x4 3x14mm BHCS 9907 Grommet Plug 89218 x4 3x8mm Washer Transponder not included! ! When spacing your Servo not servos, make sure the included! servo does not touch the chassis when installed. Receiver not included! 6727 x2 Servo Tape 89023 x2 Servo Spacer 9907 Receiver Box Grommet 81262 x2 4x10mm FHCS 81303 Receiver Box :: Receiver Box / Linkage Build - Bag 11.1, 11.
PAGE 22
:: Center Bulkhead / Brakes Build - Bag 7.1, 7.2 - Step 1 (RC8T3.1 Nitro) ! RC8T3.1 Nitro Build Continued Align slotted holes on the same side when installing brake pads. 81036 Center Bulkhead 81038 x2 Brake Pad Spring 89149 x2 Brake Bolt 81039 x2 Brake Pad Build x2 :: Center Bulkhead / Brakes Build - Bag 7.1, 7.2 - Step 2 (RC8T3.1 Nitro) Narrow 18.40mm (0.72”) 81037 Brake Rotor 31448 2.
PAGE 23
:: Center Bulkhead / Brakes Build - Bag 7.1, 7.2 - Step 4 (RC8T3.1 Nitro) (not included) 4671 3x10mm Set Screw, front 25225 3x3mm Set Screw, rear 6 #159 k d loc a e r th 81042 x2 Brake Lever ! Center brake levers between the brake cams. :: Center Bulkhead / Brakes Build - Bag 7.1, 7.2 - Step 5 (RC8T3.1 Nitro) Towards Front of Vehicle 89214 x4 4x12mm FHCS 89214 x4 4x12mm FHCS :: Radio Tray Build - Bag 10.1, 10.2 - Step 1 31448 x4 2.
PAGE 24
:: Radio Tray Build - Bag 10.1, 10.2 - Step 2 25201 x2 3x8mm FHCS 31448 2.5x8mm FHCS 25187 x4 3x14mm BHCS 89218 x4 3x8mm Washer Servo not included! 89023 x2 Servo Spacer 81102 Transponder Mount 25187 x4 3x14mm BHCS 89218 x4 3x8mm Washer 89023 x2 Servo Spacer ! When spacing your servos, make sure the servo does not touch the chassis when installed. :: Radio Tray Build - Bag 10.1, 10.
PAGE 25
:: Radio Tray Build - Bag 10.1, 10.2 - Step 5 6338 Antenna Tube and Cap 25225 3x3mm Set Screw ! 81102 Receiver Box Lid When using a receiver switch, you will need to carefully remove material from the receiver box lid in the highlighted sections below in order to mount your switch. Receiver not included! 6727 Servo Tape :: Radio Tray Build - Bag 10.1, 10.2 - Step 6 89214 x5 4x12mm FHCS 31448 x6 2.
PAGE 26
:: Servo Horns / Linkage Build - Bag 11.1, 11.2 - Step 1 91048 HD Ball Stud, 8mm 1401 33mm Turnbuckle 81250 Servo Horn (Steering) and Cone Washer 91453 x2 HD Ball Cup 25215 M3 Locknut, Black 81250 Servo Horn Insert 91050 HD Ball Stud, 12mm Printed here A - Airtronics F - Futaba H - Hitec J - JR/KO Steering Servo Turnbuckle 11.50mm (0.45”) 81250 Servo Horn Large Ring :: Servo Horns / Linkage Build - Bag 11.1, 11.
PAGE 27
:: Servo Horns / Linkage Build - Bag 11.1, 11.2 - Step 4 (not included) 81251 x2 Brake Linkage Spring Ball 25201 3x8mm FHCS 8433 x2 .024 Spring #1596 thread lock 81251 x2 Set Collar #1596 thread lock (not included) Racer’s Tip: Center servo before horn installation! 25225 x2 3x3mm Set Screw :: Engine / Tank Build - Bag 12.1, 12.
PAGE 28
:: Engine / Tank Build - Bag 12.1, 12.2 - Step 2 Engine not included! 81371 Flywheel Collet 81372 Flywheel Nut 81370 Flywheel, 4-Shoe 81373 x4 Clutch Shoe Pins :: Engine / Tank Build - Bag 12.1, 12.2 - Step 3 81366 Clutch Shoe Spring, Green, 0.95mm Clutch Shoe / Spring Installation Order: 81402 Clutch Shoe, Composite ! Short end of clutch shoe spring installed into flywheel. Long end of clutch shoe spring installed into clutch shoe. 81375 Clutch Shoe, Aluminum 81365 Clutch Shoe Spring, Black, 0.
PAGE 29
:: Engine / Tank Build - Bag 12.1, 12.2 - Step 5 81124 Air Filter Cap 81124 Air Filter 81124 Air Filter Boot tr foa ea m #7 tm 71 ent 0 3719 Nylon Wire Tie, 6” tr foa ea m #7 tm 71 ent 0 81125 Air Filter Element 25620 3x10mm SHCS ! 3719 Nylon Wire Tie, 6” When oiling the filter elements, place both inside a plastic bag and squeeze to help evenly coat the filter. :: Engine / Tank Build - Bag 12.1, 12.
PAGE 30
:: Engine / Tank Build - Bag 12.1, 12.2 - Step 6 ! When installing your engine, make sure the rear drive shaft does not interfere with the engine mount. You may need to remove material from the engine mount for fitment. 6 #159 k d loc threa 81114 x4 Engine Mount Washer 81262 x4 4x10mm FHCS :: Engine / Tank Build - Bag 12.1, 12.2 - Step 7 2208 Large Hood Pin 6 #159 k d loc threa Exhaust Set Screw not included! :: Engine / Tank Build - Bag 12.1, 12.
PAGE 31
:: Wheels / Tires / Body - Misc. - Step 1 ! Wheels, Tires, and Foam Inserts Not Included! ! 97 #15 lue ire g t A C Build four wheels/ tires Tires: When gluing tires to wheels, use a fast-curing tire glue (CA) (AE #1597). This is available at your local hobby shop. Make sure to clean the mounting surface of the tire and wheel with alchohol for best adhesion. :: Wheels / Tires / Body - Misc. - Step 2 ! Install wheel nuts (#81082) with the serrated edge towards the wheel.
PAGE 32
:: Droop Settings Set droop by measuring overall length of shock (from standoff to shock pin) while the chassis is elevated above your working surface. The shocks should be fully extended. Kit setup for front droop is 104mm shock length, and 124mm shock length for the rear. If the shock length is too long, adjust by turning the droop screws clockwise. If the shock length is too short, adjust by turning the droop screws counter-clockwise.
PAGE 33
:: Shock Fluid :: Shocks 81156 81157 81160 81161 81172 81173 81176 81177 81179 81181 81184 81185 81186 81188 81191 81194 81200 89215 81221 81407 89278 91492 RC8B3 Shock Kit (Front) - Requires #81172, 81191 RC8B3 Shock Kit (Rear) - Requires #81173, 81191 RC8B3 Shock Body, 30.5mm RC8B3 Shock Body, 39.5mm RC8T3 Shock Shaft, 33.5mm (TiN) RC8T3 Shock Shaft, 42.5mm (TiN) RC8T3 FT Chrome Shock Shafts, 3.5x33.5 mm RC8T3 FT Chrome Shock Shafts, 3.5x42.
PAGE 34
:: Front / Rear Gear Differential :: Differential Fluids 5444 5446 5447 5448 5450 5451 5452 5453 5454 5455 5456 5457 5458 5459 5461 5463 5464 Silicone Silicone Silicone Silicone Silicone Silicone Silicone Silicone Silicone Silicone Silicone Silicone Silicone Silicone Silicone Silicone Silicone Diff Diff Diff Diff Diff Diff Diff Diff Diff Diff Diff Diff Diff Diff Diff Diff Diff Fluid Fluid Fluid Fluid Fluid Fluid Fluid Fluid Fluid Fluid Fluid Fluid Fluid Fluid Fluid Fluid Fluid 4,000CST 6,000CST 15,0
PAGE 35
:: Center Bulkhead (RC8T3.1e) 25211 25224 31448 31532 81262 81299 81300 81304 89206 89512 89513 89514 89515 89516 89517 89593 89594 89595 3 x 10mm BHCS M4 x 4mm Set Screw 2.
PAGE 36
:: Front Gearbox 4675 25620 31521 81007 81015 81020 81050 81060 81113 81257 81259 81260 81264 81291 81292 81316 89214 89221 91561 2.5 x 6mm FHCS 6 3 x 10mm SHCS 20 2.5 x 8mm BHCS 6 RC8B3 Diff Pinion Gear, 10T - V2 1 RC8B3 Gearbox 2 RC8B3 Center Universal, 76mm 1 RC8B3 Arm Mount Insert 12 ea. RC8B3 Hinge Pin Set 1 RC8B3 Front Bumper 1 3 x 6mm Set Screw 6 2.5 x 18mm BHCS 6 4 x 14mm BHCS 6 4 x 20mm FHCS 6 RC8B3.1 Arm Mount, A 1 RC8B3.1 Arm Mount, B 1 RC8T3 Front Arms/Shims Pr.
PAGE 37
:: Steering 25201 25211 31404 81083 81084 81086 81088 81089 81091 81262 81397 89161 3 x 8mm FHCS 3 x 10mm BHCS Bearing, 6 x 10 x 3mm Servo Saver Spring RC8B3.1 Servo Saver Tube RC8B3 Steering Bellcrank RC8B3 Steering Bellcrank Nut RC8B3 Steering Rack RC8B3 Steering Post 4 x 10mm FHCS Turnbuckle Ball, 4mm FT Steering Bearing Set, 5 x 8 x 2.5mm & 6 x 10 x 3mm 20 20 2 1 1 1 2 1 2 6 31404 81084 81083 81088 89161 4 ea.
PAGE 38
:: Front Suspension 25202 25211 25225 81056 81060 81063 81065 81067 81070 81072 81082 81093 81197 81257 81316 81317 81319 81320 81326 81328 81331 89096 89203 89221 89317 91565 91566 3 x 10mm FHCS 3 x 10mm BHCS 3 x 3mm Set Screw RC8B3 Suspension Arm Endcap RC8B3 Hinge Pin Set Steering Block Arms, +2 deg., alum.
PAGE 39
:: Radio Tray / Servo Linkage (RC8T3.1e) 1401 6338 9907 25187 25202 25215 25225 31386 31448 81250 81262 81303 89023 89218 91048 91050 91453 FT Ti Turnbuckle, 33mm Antenna Tube with Cap, Black Receiver Box Grommets 3 x 14mm BHCS 3 x 10mm FHCS M3 Locknut, Black 3 x 3mm Set Screw Bulkhead Washers, 7.8x2.0mm 2.
PAGE 40
:: Radio Tray (RC8T3.1 Nitro) 6338 9907 25187 25201 25225 31448 31531 81100 81102 81103 89023 89214 89218 Antenna Tube with Cap, Black Receiver Box Grommets 3 x 14mm BHCS 3 x 8mm FHCS 3 x 3mm Set Screw 2.5 x 8mm FHCS 3 x 6mm BHCS RC8B3 Radio Tray RC8B3 Receiver Box RC8B3 Receiver Battery Tray Servo Mount Spacers 4 x 12mm FHCS 3 x 8mm Washer 1 2 ea.
PAGE 41
:: Front Chassis Brace 25201 81030 81032 81049 81050 81262 89214 89216 :: Rear Chassis Brace 3 x 8mm FHCS RC8B3 Top Plate RC8B3 Chassis Brace RC8B3 Upper Link Mount RC8B3 Arm Mount Insert 4 x 10mm FHCS 4 x 12mm FHCS M4 Locknut 20 1 Pr. 1 12 ea. 6 10 10 25188 25215 81032 89214 89216 3 x 20mm BHCS M3 Locknut, Black RC8B3 Chassis Brace 4 x 12mm FHCS M4 Locknut 20 20 Pr.
PAGE 42
:: Clutch (RC8T3.1 Nitro) 81365 81366 81367 81368 81369 81370 81371 81372 81373 81374 81375 81377 81402 89148 89218 89223 91560 Clutch Springs (0.90, 4 Shoe) - KIT Clutch Springs (0.95, 4 Shoe) - KIT Clutch Springs (1.00, 4 Shoe) Clutch Springs (1.05, 4 Shoe) Clutch Springs (1.10, 4 Shoe) RC8B3.1 Flywheel (4 Shoe) RC8B3.1 Flywheel Collet (4 Shoe) RC8B3.
PAGE 43
:: Chassis (RC8T3.1e) 25201 31541 81001 81311 3 x 8mm FHCS 3 x 6mm FHCS RC8B3 Side Guards RC8T3e Chassis 20 6 Pr. 1 81001 25201 31541 31541 81001 25201 25201 25201 81311 31541 31541 25201 25201 :: Chassis (RC8T3.1 Nitro) 7732 25201 25620 31541 81001 81114 81115 81118 81262 81310 4 x 4mm Set Screw 3 x 8mm FHCS 3 x 10mm SHCS 3 x 6mm FHCS RC8B3 Side Guards RC8B3 Engine Mount Washers RC8B3 Engine Mount RC8B3 Pipe Mount 4 x 10mm FHCS RC8T3 Chassis 6 20 20 6 Pr. 4 Pr.
PAGE 44
:: Reedy Motors :: Factory Team and Option Parts 2357 7733 25094 25392 27128 29213 31550 81064 81068 81077 81085 81092 81116 81117 81301 81327 81396 81405 81406 81407 81410 81413 89094 89123 89147 89405 89406 92100 Rear Exhaust Manifold Springs 2 Exhaust Tubing Coupler 1 Exhaust Manifold Springs 2 3mm Blue Locknut, Flanged 10 Servo Washers, aluminum, black 4 Servo Wire Extension, 3” 1 M3 Aluminum Lock Nut 6 FT RC8B3 Graphite Steering Block Arms, +2 deg. Pr.
PAGE 45
:: Fueling Supplies (RC8T3.1 Nitro) 1738 1747 1751 7724 7725 FT Glow Starter Nitro Fuel Bottle Pro, 500cc FT Compact Starter Box Fuel Line 15” Fuel Line 3’ :: Lubes / Adhesives / Decals / Misc.
PAGE 46
Driver: Date: Kit Setup Track: Event: Qualify: TQ: Main: Finish: Best Lap Time: Front Suspension: Ride Height: Upper Ball Type: 37mm Wheelbase Shim: Behind Arm Steel Camber: Toe: +2 deg Tierod+ 62mm Anti-Roll Bar Size: 2.3 Black Gap: 1mm Ackerman Notes: CVAs: Short: Universals: Long: Chassis Brace: Lower Ball Type: 1.
PAGE 47
Driver: Date: Track: Event: Qualify: TQ: Main: Finish: Best Lap Time: Front Suspension: Upper Ball Type: Ride Height: Wheelbase Shim: Camber: Toe: Anti-Roll Bar Size: Caster Shim: Gap: Ackerman 1 2 3 4 5 Notes: Drive Shaft: CVAs: Short: Universals: Long: Chassis Brace: Lower Ball Type: Upper Ball Shim: 54 32 1 Upper Arm Mount: Washers: Arm Mount A: Hex: BA Notes: Arm Mount B: Lower Ball Shim: Rear Suspension: 54 32 1 Hub Shim: Ride Height: Camber: Anti-Roll Bar Size: Gap: Dr
PAGE 48
Kit Setup Driver: Date: Track: Event: Qualify: TQ: Main: Finish: Best Lap Time: Front Suspension: Ride Height: Upper Ball Type: 37mm Wheelbase Shim: Behind Arm Steel Camber: Toe: +2 deg Tierod+ 62mm Anti-Roll Bar Size: 2.3 Black Gap: 1mm Ackerman Upper Ball Shim: 1 2 3 4 5 Notes: CVAs: Chassis Brace: Short: Universals: Long: Drive Shaft: Hex: 0 Caster Shim: Lower Ball Type: 1.
PAGE 49
Driver: Date: Track: Event: Qualify: TQ: Main: Finish: Best Lap Time: Front Suspension: Ride Height: Upper Ball Type: Wheelbase Shim: Camber: Toe: Anti-Roll Bar Size: Caster Shim: Gap: Ackerman 1 2 3 4 5 Notes: CVAs: Chassis Brace: Short: Universals: Long: Drive Shaft: Lower Ball Type: Upper Ball Shim: 54 32 1 Upper Arm Mount: Washers: Arm Mount A: Hex: BA Notes: Arm Mount B: Lower Ball Shim: Rear Suspension: Ride Height: 54 32 1 Hub Shim: Camber: Anti-Roll Bar Size: Gap: Dri
PAGE 50
Associated Electrics, Inc. 26021 Commercentre Dr. Lake Forest, CA 92630 USA http://www.RC10.com https://twitter.com/Team_Associated https://www.instagram.com/teamassociatedrc/ https://www.facebook.com/TeamAssociated/ call: (949) 544-7500 - fax: (949) 544-7501 Check out the following web sites for all of our kits, current products, new releases, setup help, tips, and racing info! www.TeamAssociated.com. - www.RC10.
