ASC80937 RC8T3.1 Manual

12
:: Front Uprights Build - Bag 4.1, 4.2 - Step 4
:: Rear Gearbox Build - Bag 5.1, 5.2 - Step 1
:: Rear Gearbox Build - Bag 5.1, 5.2 - Step 2
89221
5x4mm
Set Screw
81015
Gearbox,
(Inboard)
81015
Dust Cap
91561
6x12x4mm
FT Bearing
4675
2.5x6mm
FHCS
x2
#1596
thread lock
89214
4x12mm
FHCS
81264
4x20mm
FHCS
81113
Front
Bumper
x2
x2
81023
Center
Universal,
(165mm)
(not included)
81007
Diff Pinion
Gear, 10T, V2
Racer’s Tip:
Use black grease
(#6588) to lube
the Diff Pinion gear
before installation!
#6588
black grease
25620
3x10mm
SHCS
81381
Diff Shim
13.5x15.8x0.20mm
x2
81015
Gearbox,
(Outboard)
81015
Anti-Roll
Bar Cap
81259
2.5x18mm
BHCS
Step 1:
Add shims on this side to
TIGHTEN gear mesh.
Subtract shims on this side
to LOOSEN gear mesh.
Step 2:
Add or subtract shims here
to finalize diff side to side
play once gear mesh is
set from Step 1.
Recommended diff side to
side clearance (gearbox
assembly) 0.10 - 0.25mm.
Notes:
0.1mm shim can be used for
fine tuning of gear mesh.
STEP 1
STEP 2
!
!
NOTE:
Install the REAR Diff!
#6588
black grease
#1596
thread lock
81262
4x10mm
FHCS
89216
M4
Locknut,
Black
x2
89214
4x12mm
FHCS
(not included)
