:: Center Bulkhead Build - Bag 7.1, 7.2 - Step 1 (RC8T3.1e)
:: Rear Uprights / Turnbuckles Build - Bag 5.2, 6.1 - Step 4
81093
Rod End,
4mm, curved
81320
4x85mm
Turnbuckle
81093
Rod End,
4mm
Steering Turnbuckle
62.0mm (2.44”)
31448
2.5x8mm
FHCS
81304
RC8B3e Center
Bulkhead
81304
RC8B3e
Wire Guide
25211
3x10mm
BHCS
81304
RC8B3e
Bulkhead
Cover
x4
81262
4x10mm
FHCS
81299
RC8B3e
Motor Mount
x4
#1596
thread lock
(not included)
RC8T3.1e Electric Kit and RC8T3.1 Nitro Kit
If you are building an RC8T3.1e Electric kit, continue on
to Center Bulkhead Build below this step.
If you are building an RC8T3.1 Nitro kit, go to page 17
to build the Anti-Roll Bars then the Shocks. Then go to
page 22 to continue with the RC8T3.1 Nitro build.
