ASC80937 RC8T3.1 Manual

22
RC8T3.1 Nitro
Build Continued
:: Center Bulkhead / Brakes Build - Bag 7.1, 7.2 - Step 3 (RC8T3.1 Nitro)
81256
C-Clip,
5mm
81040
Brake
Cam
81043
Center
Top Plate
x2
x2
18.40mm (0.72”)
Note direction of
center diff.
!
:: Center Bulkhead / Brakes Build - Bag 7.1, 7.2 - Step 1 (RC8T3.1 Nitro)
:: Center Bulkhead / Brakes Build - Bag 7.1, 7.2 - Step 2 (RC8T3.1 Nitro)
89149
Brake
Bolt
31448
2.5x8mm
FHCS
81037
Brake
Rotor
81038
Brake
Pad
Spring
81036
Center
Bulkhead
x2
x2
81039
Brake Pad
81036
Rotor
Guide,
Narrow
x2
Align slotted holes on the same side
when installing brake pads.
Wide Rotor Guide
used for optional
#89123 Heat
Sink Brake Disc.
!
Build x2
Build x2
Wide
Narrow
