ASC80937 RC8T3.1 Manual

41
:: Front Chassis Brace
25201
81030
81032
81049
81050
81262
89214
89216
20
1
Pr.
1
12 ea.
6
10
10
3 x 8mm FHCS
RC8B3 Top Plate
RC8B3 Chassis Brace
RC8B3 Upper Link Mount
RC8B3 Arm Mount Insert
4 x 10mm FHCS
4 x 12mm FHCS
M4 Locknut
:: Rear Chassis Brace
25188
25215
81032
89214
89216
20
20
Pr.
10
10
3 x 20mm BHCS
M3 Locknut, Black
RC8B3 Chassis Brace
4 x 12mm FHCS
M4 Locknut
89214
89214
89216
81032
81032
25188
25215
89214
81262
89214
89214
89216
89216
81032
81030
81050
81049
25201
:: Anti-Roll Bars
25225
81130
81131
81140
81141
81150
81258
20
1 ea.
1 ea.
1 ea.
1 ea.
1
6
3 x 3mm Set Screw
RC8B3 Front Anti-Roll Bars,
(2.3 - Black, 2.4 - Green, 2.5 - White)
RC8B3 Front Anti-Roll Bars,
(2.6 - Gray, 2.7 - Blue, 2.8 - Yellow
RC8B3 Rear Anti-Roll Bars,
(2.5 - White, 2.6 - Gray, 2.7 - Blue)
RC8B3 Rear Anti-Roll Bars,
(2.8 - Yellow, 2.9 - Red, 3.0 - Orange)
RC8B3 Anti-Roll Bar Drop Link / Collet
3 x 12mm Set Screw
25225
25225
81150
81150
81150
81150
81150
81258
81130
81131
81140
81141
:: Wing
25187
25203
25215
81106
81108
81109
81263
20
20
20
1
1
1
6
3 x 14mm BHCS
3 x 12mm FHCS
M3 Locknut, Black
RC8B3 Wing, Black (1 wing, 2 wing buttons)
RC8B3 Wing Mount, 1 low
RC8B3 Wing Mount, high (+8mm)
4 x 16mm FHCS
25215
25187
81263
25203
81106
81106
81106
81108
25215
