Installation Instructions

2
4
MOUNTING
PLATE
ELECTRICAL BOX
3B
#8-32 SCREW
4
#8-32 SCREW
4
Leave 6" of the cord behind the canopy for power
connections. Cut the excess cord.
From the end of the cord, strip the insulation 4" using a
sharp knife. .Make sure not to nick the inner wires
Strip the end of the wires.
1
2
3
3A
6"
5
MOUNTING
PLATE
ELECTRICAL BOX
3C
Connect the ground wire to a suitable ground in
accordance with local electrical codes.
Connect the black wire to the neutral power wire with a
wire nut.
Connect the red wire to the hot power wire with a wire
nut.
Neatly place all wires and wire nut connections in the
electrical box and reinstall the canopy to the mounting
plate (reversal of step 1A).
6
7
Install the Fixture
Install the Lamps
1
Screw the lamps into the sockets.
C AUTION: To reduce the risk of a burn or electric
shock during re-lamping, disconnect the power to
the fixture.
Refer to fixture marking for lamp information.
SAVETHESE INSTRUCTIONS!
4A
SOCKET
LAMP
5
7
6
8
Secure the mounting plate to the electrical box with the
two provided #8-32 screws.
