MusicMan

Mini Style MP3 Player TX-52

User Manual

The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/ (in bottom

bar “Konformitätserklärung”). Before using the device the first time, read the user manual carefully.

This device has a rechargeable battery. It must be fully charged before first use.

Service phone No. for technical support: 01805 012643 (14 cent/minute from German fixed-line

and 42 cent/minute from mobile networks). Free Email: support@technaxx.de

NOTE: Charge the battery of the device every 2–3 month if it is not used!

Features



MP3 Player



USB 2.0



Supports MP3 & WMA music formats



Built-in MicroSD card slot



Supports MicroSD cards up to 32GB (Fat32 formatted)



Built-in port for earphones



Elegant aluminium shell



Very small pocket size, practicable to take everywhere you want

Technical Specifications

Music format MP3 & WMA

Bit rate 8 ~ 320 kbps

Battery Built-in rechargeable 130mAh lithium polymer battery

Charging time 1.5 ~ 2 hours

Playing time ~ 7 hours

Environmental temperature –20 ~ +60°C

Relative humidity 20% ~ 93% (40°C)

Weight / Dimensions 10 g / (L) 2.1 x (W) 2.1 x (H) 2.1 cm

Package Contents

MusicMan® Mini Style MP3 Player TX-52, Earphones,

3.5mm Jack cable to USB charging cable, User Manual

1. Charging

Before first use, fully load the battery with the included original USB/3.5mm charging cable.

Plug in the charging cable into the 3.5mm slot of the player (6) and the other side to the

USB slot of your PC/Notebook or another USB slot of chargers. When the player is being

charged, the LED (8) turns to RED and lighting constantly. Once it is fully charged, the LED

gets OFF. (It is recommended to turn off the player while charging, because it will take

longer time to get completely charged if the player works while being charged). Please

charge the player at least 2 hours before first use! NOTE: Charge the battery of the

device every 2–3 month if it is not used!

Summary of content (3 pages)

PAGE 1
MusicMan® Mini Style MP3 Player TX-52 User Manual The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the device the first time, read the user manual carefully. This device has a rechargeable battery. It must be fully charged before first use. Service phone No. for technical support: 01805 012643 (14 cent/minute from German fixed-line and 42 cent/minute from mobile networks). Free Email: support@technaxx.
PAGE 2
. Product overview Table for the product overview 1 2 3 4 5 6 7 8 ON / OFF / PLAY / PAUSE ON Press the button (1) to get the player ON OFF Press the button (1) to get the player OFF PLAY Press the button (1) to play the paused track PAUSE Press the button (1) to pause the playing track NEXT Press short to go forth to the next song. PREV Press short to go forth to the previous song.
PAGE 3
4. Handling MicroSD card (a) Insert first the earphone in to the earphone slot (7) (b) Insert a MicroSD card into the MicroSD card slot (8). Then the music starts playing automatically. The GREEN LED (6) is blinking. To pause the music playback, press the key once; press it again and music playback will continue. (c) Press short the key to you hear the previous song. Press short the key to hear the -) key next song. Press and hold the (+) key to increase the volume.
