28 Plasma Monitor
Miscellaneous
26. Abnormal State (Command 2 : z)
G To recognize an abnormal state.
Transmission
Data 0: Normal (Power on and signal exist)
1: No signal (Power on)
2: Turn the monitor off by remote control
3: Turn the monitor off by sleep time function
4: Turn the monitor off by RS-232C function
5: 5V down
6: AC down
7: Turn the monitor off by Fan Alarm function
8: Turn the monitor off by off time function
9: Turn the monitor off by auto off function
a: Turn the monitor off by AV board detect
* This function is “read only”.
[k][z][ ][Set ID][ ][FF][ ][Cr]
Ack
[z][ ][Set ID][ ][OK][Data][x]
19. Balance (Command 2 : t)
G To adjust balance.
You can also adjust balance in the SOUND menu.
Transmission
Data Min : 0 ~ Max : 64
*
Refer to ‘Real data mapping 1’. See page 29.
[k][t][ ][Set ID][ ][Data][Cr]
Ack
[t][ ][Set ID][ ][OK][Data][x]
20. Colour Temperature (Command 2 : u)
G To adjust colour temperature.
You can also adjust CSM in the PICTURE menu.
Transmission
Data 0: Normal 1: Cool 2: Warm 3: User
[k][u][ ][Set ID][ ][Data][Cr]
Ack
[u][ ][Set ID][ ][OK][Data][x]
21. Red Adjustment (Command 2 : v)
G To adjust red in colour temperature.
Transmission
Data Min : 0 ~ Max : 64
*
Refer to ‘Real data mapping 2’. See page 29.
[k][v][ ][Set ID][ ][Data][Cr]
Ack
[v][ ][Set ID][ ][OK][Data][x]
22. Green Adjustment (Command 2 : w)
G To adjust green in colour temperature.
Transmission
Data Min : 0 ~ Max : 64
*
Refer to ‘Real data mapping 2’. See page 29.
[k][w][ ][Set ID][ ][Data][Cr]
Ack
[w][ ][Set ID][ ][OK][Data][x]
23. Blue Adjustment (Command 2 : $)
G To adjust blue in colour temperature.
Transmission
Data Min : 0 ~ Max : 64
*
Refer to ‘Real data mapping 2’. See page 29.
[k][$][ ][Set ID][ ][Data][Cr]
Ack
[$][ ][Set ID][ ][OK][Data][x]
24. PIP Input Select (Command 2 : y)
G To select input source for sub picture in PIP picture
mode. You can also adjust input source for sub pic-
ture in the PIP menu.
Transmission
Data 0 : RGB
1 : AV1
2 : AV2
3 : S-Video
4 : DVI
[k][y][ ][Set ID][ ][Data][Cr]
Ack
[y][ ][Set ID][ ][OK][Data][x]
25. SSM Mode (Command 2 : x)
G To select sound mode.
Transmission
Data 0 : Flat
1 : Speech
2 : Movie
3 : Music
4 : User
[k][x][ ][Set ID][ ][Data][Cr]
Ack
[x][ ][Set ID][ ][OK][Data][x]
18. Bass (Command 2 : s)
G To adjust bass.
You can also adjust bass in the SOUND menu.
Transmission
Data Min : 0 ~ Max : 64
*
Refer to ‘Real data mapping 1’. See page 29.
[k][s][ ][Set ID][ ][Data][Cr]
Ack
[s][ ][Set ID][ ][OK][Data][x]
