268E(15") en 1997/04/03 9:24 AM Page 2 IMPORTANT SAFETY INSTRUCTIONS Read before operating equipment 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions.
268E(15") en 1997/04/03 9:24 AM Page 3 Contents Installation English Preparation 4 Use of the remote control 5 To use the menus 6 Setup menu 6 Program/Erase channels 6 Auto programming channels 6 Memorizing/Erasing current channel 7 Operation Buttons in front of the TV 7 Picture menu 8 Sound menu 8 Closed Caption 9 Parental control functions 10 Setting up blocking 10-11 Help? If this instruction manual does not give an answer or if ‘Before Calling Service’ does not solve your TV problem, you can call
268E(15") en 1997/04/03 9:24 AM Page 4 Preparation Please, make sure to connect the power plug to the wall outlet socket after connecting the TV to the adapter! ‘ Remote control: Remove the cover of the battery compartment. Insert the 2 batteries supplied (Type R6-LR6 1.5V). & Place the TV on a solid surface. R6-LR6 / 1,5 V min. 1m ( Power:This TV operates on a DC supply Ensure that the TV is placed in a position to allow free flow of air. Do not cover the ventilation openings on the back cover.
268E(15") en 1997/04/03 9:24 AM Page 5 Use of the remote control SLEEP Sleeptimer B Standby Press to turn on/off the TV. The TV is never completely powered off unless it is physically unplugged. EXT Source Select your computer or other peripherals: press repeatedly to select TV, VIDEO, S-VIDEO, COMPONENT or PC monitor mode, according to where you connected your external source. See p. 12. • VIDEO for a VCR connected to the AV connectors of the TV.
268E(15") en 1997/04/03 9:24 AM Page 6 To use the menus & B EXT SLEEP 1 2 3 4 5 6 7 8 0 0 9 activate OK MENU é “ Use the cursor up/down to select a menu item. ‘ Press the EXT button to exit the menu. switch menu on/off CC Press the MENU button repeatedly to display each menu. Use the cursor left/right to adjust the setting of a menu item or press the OK button to enter a submenu.
268E(15") en 1997/04/03 9:24 AM Page 7 Memorizing/Erasing current channel Channel Auto ogramme Fine Storage TV 13 Memory oœ p π 0-9 MENU & Select Manual Program in the channel menu. é Press the OK button to enter the Manual Program menu. The current channel number is displayed. “ Press the cursor left/right to select another channel number. ‘ Select Storage with the cursor up/down. ( Press the cursor left/right to select Memory or Erase.
268E(15") en 1997/04/03 9:24 AM Page 8 Picture menu Contrast Brightness Color Tint Sharpness oœ p π You can adjust picture contrast, brightness, color, tint and sharpness to the levels you prefer. 100 1 00 60 60 0 6 Press the OK button to store the adjustments.The message Stored appears. OK MENU Press the EXT button if you want to exit the menu • Contrast, Brightness, Color are adjusted from 0 to 100. • Tint is adjusted from Red 50 to Green 50. • Sharpness is adjusted from 0 to 10.
268E(15") en 1997/04/03 9:24 AM Page 9 Closed Caption Closed Captioning allows you to read the dialog of television programs on the TV screen. Designed to help the hearing impaired, this feature uses on screen "text boxes" to show dialogue and conversations while the TV program is in progress. Captions will appear on the screen only during captioned broadcasts.
268E(15") en 1997/04/03 9:24 AM Page 10 Parental control function Input Language Captions Caption/Text Parental ctl oœ OK TV English Off CC1 To use the Parental Control Function, the following must be set: 1. Ratings and categories to be blocked. 2. Number of hours to lock the television viewing control. 3. Set a password. 4. Enable the lock MENU The Parental control function (V-chip) is used to block program viewing based on the ratings sent by the broadcaster.
268E(15") en 1997/04/03 9:24 AM For Movies previously • Movie Ratings: Unblocked G and above PG and above PG-13 and above R and above NC-17 and above X Page 11 shown in theaters: (general audience) (parental guidance suggested) (13 years and up) (restricted) (18 years and up) (adult) If you set PG-13 and above: G and PG movies will be available, PG-13, R, NC-17 and X will be blocked.
268E(15") en 1997/04/03 9:24 AM Page 12 Connect Peripheral Equipment Preparation Remove the backplate at the back of the TV as shown on the illustration opposite. Lay the LCD TV with the screen down on a table as it will be easier to connect your peripheral equipment. Please take your precautions not to damage the screen. There is a wide range of video and audio equipment that can be connected to your TV. The following connection diagrams show you how to connect them.
268E(15") en 1997/04/03 9:24 AM Page 13 Camera, camcorder,Video Game set, ... & é DC 12V ANT IN x 75 Pb Y Pr PC INPUT S-VIDEO IN COMPONENT INPUT (480i) VIDEO How to connect Connect your camera, camcorder, videogame set, ... to the VIDEO port 2 and AUDIO L (MONO) 3 for mono equipment. For stereo equipment also connect AUDIO R 3. S-VHS quality with an S-VHS camcorder is obtained by connecting the S-VHS cables with the S-VIDEO input 1 and AUDIO input 3.
268E(15") en 1997/04/03 9:24 AM Page 14 Digital Set Top Box & DC 12V ANT IN x 75 Pb Y Pr PC INPUT COMPONENT INPUT (480i) S-VIDEO IN VIDEO (MONO) L AUDIO R AV é 2 1 How to connect Connect the three separate component video cables 1 to the DTV player’s Y, Pb and Pr ports and to the Y, Pb and Pr (480i) ports on the TV. Connect the audio cables 2 to the DTV player’s AUDIO L and R ports and to the L (MONO) and R AUDIO AV ports on the TV.
268E(15") en 1997/04/03 9:24 AM Page 15 Personal computer Monitor Display modes DC 12V & é “ ‘ ANT IN x 75 Y Pb Pr COMPONENT INPUT (480i) S-VIDEO IN VIDEO (MONO) L AUDIO R AV Connect one end of a (male to male) VGA cable to the video card of the computer and the other end to the VGA connector PC INPUT at the back of the TV. Fix the connectors firmly with the screws on the plug. Note: the VGA cable is not supplied with the TV.
268E(15") en 1997/04/03 9:24 AM Page 16 Use of the PC menu Input H G ≈ Ú Clock Clock phase Auto configure Reset oœ pπ Clock Press the cursor left/right to minimize any vertical bars or stripes visible on the screen background. PC 60 90 0 0 40 16 Clock phase Press the cursor left/right to, when necessary, adjust the pixel phase of the picture to avoid picture interference. Auto-configure Select Auto-configure On for the automatic adjustment of the screen position, clock and clock phase.
268E(15") en 1997/04/03 9:24 AM Page 17 Before Calling Service Please make these simple checks before calling service.These tips may save you time and money since charges for receiver installation and adjustments of customer controls are not covered under your warranty. Symptoms Items to Check and Actions to follow “Ghost” or double images • No power • • No picture • • • • • This may be caused by obstruction to the antenna due to high rise buildings or hills.
268E(15") en 1997/04/03 9:24 AM Page 18 Glossary Audio/Video Inputs Located on the rear and the front of the receiver these connectors (RCA phono type plug) are used for the input of audio and video signals. Designed for use with VCRs (or other accessories) in order to receive higher picture resolution and offer sound connection options. Menu An on-screen listing of feature controls shown on the TV screen that are made available for user adjustments.
268E(15") en 1997/04/03 9:24 AM Page 19 Conversion Table A: channel to frequency (in MHz) for off-air channels. The frequencies used by a cable company may differ from the frequencies on the table. Consult your cable company or your dealer for detailed information. Channel 2 3 4 5 6 7 8 9 10 11 12 13 MHz 55.25 61.25 67.25 77.25 83.25 175.25 181.25 187.25 193.25 199.25 205.25 211.25 Channel 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 MHz Channel MHz Channel MHz 471.
