42" External S peaker (Optional) Ins tallation

Speaker Installation

• Turn off monitor power before making any connections .

P lace the speakers in the position you want. Install the speaker wires on the monitor and speaker. B e sure to connect the

positive Ò+Ó wire to the Ò+Ó input and the negative Ò-Ó wire to the ÒÐÓ input. C onnect left monitor input to left speaker and right

monitor input to right speaker. Any extra speaker wire length remaining can be bunched into the wire holders provided.

(C aution: Once installed, the speaker wire holders lock into position and canÕt be removed.)

• Match the color of each connection on the speaker and monitor
