Monitor Installation
OWNER'S MANUAL
19
50" Speaker (Optional) Installation
• Always lift the monitor itself (not the speakers) when handling or moving the monitor after speakers have been installed.
Assemble the monitor to speaker using the supporter hanger and bolt. As shown above A, assemble the a and b of
supporter hanger to the monitor using the bolt(M4x8). Assemble the c, d and e to the speaker using the
bolt(4x16). If the bolts are tightened too much, the product could be damaged.
• Match the color of each connection on the speaker and monitor.
