Performance Data Sheet

AE3440Y-AA1A

General Information

Model AE3440Y-AA1A Refrigerant R-134a

Test Condition ASHRAE Performance Test Voltage 115V ~ 60HZ

Return Gas 20°C (68°F) RETURN GAS Motor Type RSIR

Performance Information

Condensing Temperature (°F)

Evap Temp (°F)

80 90 100 110 120 130 140

Btu/h 2100 2070 1960 1790 1580 1330 1060

Watts 311 335 352 361 363 360 352

Amps 4.67 4.77 4.84 4.88 4.89 4.87 4.83

Lb/h 26.8 27.9 27.7 26.4 24.4 21.8 18.8

Btu/h 2390 2350 2240 2060 1840 1590 1330

Watts 322 349 368 380 386 387 384

Amps 4.73 4.84 4.92 4.97 5.01 5.01 5.00

Lb/h 30.5 31.7 31.6 30.5 28.6 26.3 23.5

Btu/h 2720 2660 2530 2340 2110 1860 1600

Watts 332 361 383 399 408 414 415

Amps 4.79 4.90 5.00 5.07 5.12 5.16 5.17

Lb/h 34.6 35.7 35.7 34.7 33.0 30.7 28.2

Btu/h 3070 2990 2840 2640 2400 2130 1860

Watts 340 372 397 416 429 439 445

Amps 4.84 4.97 5.07 5.17 5.24 5.30 5.34

Lb/h 39.1 40.2 40.1 39.2 37.5 35.4 33.0

Btu/h 3470 3360 3180 2960 2690 2410 2130

Watts 347 381 409 432 449 463 474

Amps 4.89 5.02 5.15 5.26 5.36 5.44 5.52

Lb/h 44.2 45.1 45.0 44.0 42.4 40.3 38.0

Btu/h 3910 3770 3560 3300 3020 2710 2410

Watts 352 389 420 446 468 486 502

Amps 4.92 5.07 5.22 5.35 5.47 5.59 5.69

Lb/h 49.9 50.7 50.5 49.4 47.7 45.6 43.4

Btu/h 4400 4220 3970 3680 3370 3040 2710

Watts 356 396 430 459 485 508 528

Amps 4.95 5.12 5.28 5.43 5.58 5.73 5.86

Lb/h 56.4 57.0 56.6 55.4 53.6 51.4 49.1

Btu/h 4960 4720 4440 4110 3760 3390 3040

Watts 358 400 438 471 501 528 554

Amps 4.97 5.15 5.33 5.51 5.69 5.86 6.03

Lb/h 63.9 64.2 63.5 62.1 60.1 57.8 55.4

PAGE 1
Performance Data Sheet AE3440Y-AA1A General Information Model AE3440Y-AA1A Refrigerant R-134a Test Condition ASHRAE Performance Test Voltage 115V ~ 60HZ Return Gas 20°C (68°F) RETURN GAS Motor Type RSIR Performance Information Condensing Temperature (°F) Evap Temp (°F) Btu/h 80 90 100 110 120 130 140 2100 2070 1960 1790 1580 1330 1060 Watts 311 335 352 361 363 360 352 Amps 4.67 4.77 4.84 4.88 4.89 4.87 4.83 5 Lb/h 26.8 27.9 27.7 26.4 24.4 21.8 18.
PAGE 2
Btu/h 5570 5290 4960 4580 4190 3790 3390 Watts 358 403 444 481 515 547 578 Amps 4.98 5.18 5.38 5.58 5.79 5.99 6.20 Lb/h 72.3 72.3 71.3 69.6 67.4 64.9 62.4 45 Btu/h 6260 5920 5530 5110 4670 4220 3790 Watts 356 405 449 490 528 565 601 Amps 4.98 5.20 5.42 5.64 5.88 6.11 6.36 Lb/h 81.9 81.4 80.1 78.1 75.6 72.9 70.2 Btu/h 7030 6630 6180 5700 5200 4710 4230 50 Watts 353 404 452 497 539 581 622 Amps 4.96 5.20 5.44 5.69 5.96 6.
