AE4430Y-XN1A

General Information

Model AE4430Y-XN1A Refrigerant R-134a

Test Condition EN12900 ASERCOM Performance Test Voltage 220V ~ 50HZ

Return Gas 20°C (68°F) RETURN GAS Motor Type CSIR

Performance Information

Condensing Temperature (°C)

Evap

Temp (°C)

30 40 50 60

Watts

(Capacity)

364 317 259 199

Watts (Power) 235 248 257 261

Amps 2.33 2.34 2.34 2.34

-15

Lb/h 7.43 7.03 6.34 5.51

Watts

(Capacity)

468 413 347 279

Watts (Power) 250 265 278 287

Amps 2.35 2.35 2.36 2.37

-10

Lb/h 9.54 9.17 8.50 7.67

Watts

(Capacity)

548 485 412 336

Watts (Power) 259 277 293 305

Amps 2.37 2.37 2.38 2.40

-6.7

Lb/h 11.2 10.8 10.1 9.27

Watts

(Capacity)

593 526 448 368

Watts (Power) 264 283 301 315

Amps 2.38 2.38 2.40 2.41

-5

Lb/h 12.1 11.7 11.0 10.2

Watts

(Capacity)

743 659 565 469

Watts (Power) 276 300 323 343

Amps 2.40 2.42 2.44 2.47

Lb/h 15.2 14.8 14.0 13.1

Watts

(Capacity)

922 817 703 585

Watts (Power) 285 315 344 371

Amps 2.42 2.45 2.49 2.54

Lb/h 19.1 18.5 17.6 16.5

Watts

(Capacity)

1010 895 770 643

7.2

Watts (Power) 287 320 353 382
