Technical Data Sheet

Technical Data Sheet
2/13/2015
Model: AE4440Z-AA1A
Product Description
Type: Reciprocating
Application: HBP/CBP - High/Commercial
Back Pressure
Refrigerant: R-404A
Voltage/Frequency: 115V ~ 60Hz
Version: N/A
Product Specifications
Performance
Refrigeration Capacity Input Power Efficiency
Condition Test Voltage Btu/h kcal/h W W Btu/Wh kcal/Wh W/W
EVAP TEMP COND
TEMP
AMBIENT
TEMP
RETURN
GAS
LIQUID
TEMP
ASHRAE 115V ~ 60HZ 4350 1096 1275 563 7.73 1.95 2.26 7.2°C (45°F) 54°C (130°F) 35°C (95°F) 35°C (95°F) 46°C (115°F)
General
Evaporating Temp. Range: -15°C to 15°C (5°F to 59°F)
Motor Torque: High Start Torque (HST)
Compressor Cooling: Fan
Mechanical
Weight: 0
Weight Unit of Measure: N/A
Displacement (cc): 6.69
Oil Type: Polyolester
Viscosity (cSt): 32
Oil Charge (cc): 285
Electrical
Voltage Range (50 Hz): N/A
Voltage Range (60 Hz): 103-127
Locked Rotor Amps (LRA): 36
Rated Load Amps (RLA 50 Hz): 0
Rated Load Amps (RLA 60 Hz): 6.3
Max. Continuous Current (MCC in Amps): 0
Motor Resistance (Ohm) - Main: 1.37
Motor Resistance (Ohm) - Start: 3.85
Motor Type: CSIR
Overload Type: N/A
Relay Type: N/A
Agency Approval
cURus Recognized
