Performance Data Sheet

March 7, 2014
Revision: A
Celseon® Air Cooled
Condensing Unit
Model: AE4456Y-AA1CD*
BoM: 2G226-** R-134a 1/2 HP
Model
Dimensions, inches
Line Connection*
Pumpdown
Air
Oil Ch
Gr. Wt.
L
W
H
CH
Suction
Liquid
90 °F 90%
SCFM
Oz.
Lbs.
AE4456Y-AA1CDA
16.0 14.3 11.1 9.3
3/8” S
1/4” S
N/A
185 9.5
39
AE4456Y-AA1CDG
3/8” S
3/8” S
2.9 lbs
41
AE4456Y-AA1CDH
3/8” S
3/8” S
N/A
39
AE4456Y-AA1CDK
3/8” S
1/4” S
39
AE4456Y-AA1CDC
3/8” S
3/8” S
2.9 lbs
41
AE4456Y-AA1CDS
3/8” S
3/8” S
N/A
39
AE4456Y-AA1CDJ
3/8” S
3/8” S
2.9 lbs
41
AE4456Y-AA1CDP
3/8” S
3/8” S
2.9 lbs
41
* F = Flare, S = Solder, RF or RS = Rotolock with Flare or Solder Connections, C = Compression Fitting
Factory charge: 20 PSIG Nitrogen – MUST BE EVACUATED
Ambient Temperatures
Evaporator T, 80°F 90°F 100°F 110°F
°F
PSIG
BTUH
Watts
Cond T
BTUH
Watts
Cond T
BTUH
Watts
Cond T
BTUH
Watts
Cond T
5 9.0 2594 487 98 2378 501 108 2169 514 117 1967 528 126
10
11.9
2923
519
101
2681
535
110
2447
550
119
2221
566
128
15
15.0
3262
552
103
2993
570
112
2734
587
121
2483
605
130
20 18.4 3610 586 106 3314 606 115 3028 626 124 2751 646 132
25
22.1
4104
634
108
3783
657
117
3472
680
126
3170
703
135
30
26.1
4480
673
111
4131
698
120
3793
723
128
3465
748
137
35 30.4 4859 713 114 4482 740 122 4117 767 131 3761 795 140
40
35.0
5239
755
117
4834
784
125
4440
814
134
4057
843
142
45
40.1
5617
798
119
5183
830
128
4761
861
136
4350
893
145
60 Hz Performance
Return gas temp 40°F below 20°F evaporator,
and 65°F above 20° evap, 5°F sub cooling
