Technical Data Sheet

2/13/2015

Model: AEA2415AAB

Product Description

Type: Reciprocating

Application: LBP - Low Back Pressure

Refrigerant: R-12

Voltage/Frequency: 115V ~ 60Hz 90V ~ 50Hz

Version: N/A

Product Specifications

Performance

Refrigeration Capacity Input Power Efficiency

Condition Test Voltage Btu/h kcal/h W W Btu/Wh kcal/Wh W/W

EVAP TEMP COND

TEMP

AMBIENT

TEMP

RETURN

GAS

LIQUID

TEMP

ASHRAE 115V ~ 60HZ 1525 384 447 425 3.59 .9 1.05 -23°C (-10°F) 54°C (130°F) 32°C (90°F) 32°C (90°F) 32°C (90°F)

General

Evaporating Temp. Range: -40°C to -12.2°C (-40°F to 10°F)

Motor Torque: High Start Torque (HST)

Compressor Cooling: Fan

Mechanical

Weight: 27

Weight Unit of Measure: LB

Displacement (cc): 16.077

Oil Type: Synthetic Alkylate

Viscosity (cSt): 32

Oil Charge (cc): 423

Electrical

Voltage Range (50 Hz): 81-99

Voltage Range (60 Hz): 103-127

Locked Rotor Amps (LRA): 40

Rated Load Amps (RLA 50 Hz): 0

Rated Load Amps (RLA 60 Hz): 6

Max. Continuous Current (MCC in Amps): 8

Motor Resistance (Ohm) - Main: 1.13

Motor Resistance (Ohm) - Start: 6.2

Motor Type: CSIR

Overload Type: N/A

Relay Type: N/A

Agency Approval

cURus Recognized
