Performance Data Sheet

Performance Data Sheet
AVB5535EXG
General Information
Model AVB5535EXG Refrigerant R-22
Test Condition ARI Performance Test Voltage 460V 3~ 60HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type 3PH
Performance Information
Condensing Temperature (°F)
Evap Temp (°F)
80 90 100 110 120 130 140
Btu/h 9850 7750
Watts 1320 1350
Amps 2.46 2.54
-15
Lb/h 128 104
Btu/h 12100 9960 8020
Watts 1450 1470 1510
Amps 2.58 2.65 2.73
-10
Lb/h 155 133 112
Btu/h 14500 12300 10300 8400
Watts 1570 1600 1640 1680
Amps 2.70 2.77 2.84 2.92
-5
Lb/h 185 163 143 122
Btu/h 17100 14800 12800 10800 8740
Watts 1680 1720 1770 1820 1870
Amps 2.82 2.88 2.96 3.04 3.08
0
Lb/h 217 195 175 155 131
Btu/h 19900 17500 15400 13300 11200
Watts 1780 1840 1900 1960 2010
Amps 2.93 3.00 3.08 3.16 3.22
5
Lb/h 251 229 209 189 167
Btu/h 23000 20400 18200 16000 13800 11400 8620
Watts 1870 1950 2020 2090 2160 2210 2260
Amps 3.04 3.11 3.20 3.29 3.36 3.39 3.35
10
Lb/h 288 265 245 226 204 176 141
Btu/h 26300 23600 21200 18900 16600 14100 11200
Watts 1950 2040 2140 2220 2300 2370 2420
Amps 3.13 3.21 3.32 3.42 3.51 3.56 3.54
15
Lb/h 328 304 284 264 243 216 181
Btu/h 30000 27100 24500 22000 19600 17000 14000
Watts 2010 2130 2240 2350 2440 2530 2590
Amps 3.21 3.30 3.42 3.55 3.66 3.73 3.74
20
Lb/h 371 346 325 306 284 257 223
