Performance Data Sheet

ManualsBrandsTecumseh ManualsReciprocating CompressorsTecumseh AWF5532EXG

AWF5532EXG

General Information

Model AWF5532EXG Refrigerant R-22

Test Condition ARI Performance Test Voltage 460V 3~ 60HZ

Return Gas 18.3°C (65°F) RETURN GAS Motor Type 3PH

Performance Information

Condensing Temperature (°F)

Evap Temp (°F)

80 90 100 110 120 130 140

Btu/h 8310 7270

Watts 1280 1250

Amps 2.34 2.32

-15

Lb/h 107 97.7

Btu/h 10200 9040 7940

Watts 1400 1400 1390

Amps 2.47 2.47 2.47

-10

Lb/h 131 121 111

Btu/h 12200 11000 9800 8620

Watts 1510 1530 1540 1550

Amps 2.58 2.60 2.62 2.65

-5

Lb/h 156 146 135 124

Btu/h 14500 13200 11900 10600 9260

Watts 1610 1640 1680 1720 1740

Amps 2.67 2.71 2.76 2.81 2.84

Lb/h 184 173 162 151 139

Btu/h 17000 15600 14100 12700 11300

Watts 1690 1750 1810 1860 1910

Amps 2.76 2.81 2.88 2.95 3.01

Lb/h 214 203 192 180 167

Btu/h 19800 18200 16600 15000 13400 11800 10200

Watts 1760 1840 1920 2000 2070 2120 2140

Amps 2.83 2.91 3.00 3.09 3.17 3.24 3.27

Lb/h 247 235 224 211 198 183 167

Btu/h 22800 21000 19200 17500 15800 14000 12300

Watts 1820 1920 2020 2120 2210 2290 2330

Amps 2.89 2.99 3.10 3.22 3.32 3.41 3.48

Lb/h 283 270 258 245 231 215 198

Btu/h 26000 24100 22100 20200 18400 16400 14500

Watts 1870 1990 2110 2240 2350 2450 2520

Amps 2.93 3.05 3.19 3.33 3.46 3.58 3.67

Lb/h 321 308 295 281 266 250 232

Summary of content (4 pages)

PAGE 1
Performance Data Sheet AWF5532EXG General Information Model AWF5532EXG Refrigerant R-22 Test Condition ARI Performance Test Voltage 460V 3~ 60HZ Return Gas 18.3°C (65°F) RETURN GAS Motor Type 3PH Performance Information Condensing Temperature (°F) Evap Temp (°F) 80 90 Btu/h 8310 7270 Watts 1280 1250 Amps 2.34 2.32 100 110 120 130 140 -15 Lb/h 107 97.7 Btu/h 10200 9040 7940 Watts 1400 1400 1390 Amps 2.47 2.47 2.
PAGE 2
Btu/h 29500 27400 25300 23200 21100 19000 16900 Watts 1910 2050 2200 2340 2480 2590 2690 Amps 2.97 3.11 3.27 3.44 3.60 3.74 3.86 Lb/h 362 348 335 320 305 288 269 25 Btu/h 33300 31000 28700 26400 24100 21800 19500 Watts 1940 2100 2270 2430 2590 2730 2850 Amps 3.00 3.16 3.35 3.53 3.72 3.89 4.03 Lb/h 406 392 377 362 345 328 308 Btu/h 37400 34800 32300 29900 27400 24900 22300 Watts 1960 2140 2330 2520 2700 2860 3000 Amps 3.02 3.
PAGE 3
Performance Data Sheet AWF5532EXG General Information Model AWF5532EXG Refrigerant R-22 Test Condition ARI Performance Test Voltage 380V 3~ 50HZ Return Gas 18.3°C (65°F) RETURN GAS Motor Type 3PH Performance Information Condensing Temperature (°F) Evap Temp (°F) 80 90 Btu/h 6890 6030 Watts 1040 1010 Amps 2.29 2.27 100 110 120 130 140 -15 Lb/h 89.0 81.0 Btu/h 8430 7500 6590 Watts 1140 1130 1130 Amps 2.41 2.41 2.42 -10 Lb/h 108 100 91.
PAGE 4
Btu/h 24500 22700 21000 19200 17500 15800 14000 Watts 1540 1660 1780 1890 2000 2100 2170 Amps 2.90 3.04 3.20 3.36 3.51 3.65 3.77 Lb/h 300 289 277 265 252 238 223 25 Btu/h 27600 25700 23800 21900 20000 18100 16200 Watts 1570 1700 1830 1970 2100 2210 2310 Amps 2.93 3.09 3.27 3.45 3.63 3.80 3.94 Lb/h 336 325 313 300 286 272 255 Btu/h 31000 28900 26800 24800 22700 20600 18500 Watts 1580 1730 1880 2040 2180 2310 2430 Amps 2.95 3.
