Model

5409

SWIVEL BENCH VISE

OPERATOR’S MANUAL

WARNING: WEAR

IMPACT-RESISTANT

PROTECTIVE

EYEWEAR IN WORK

AREA AT ALL TIMES.

Save time, contact us first.

888-648-8665

support@tektontools.com

NEED HELP?

Summary of content (4 pages)

PAGE 1
Model 5409 ® SWIVEL BENCH VISE OPERATOR’S MANUAL STORE THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE !? NEED HELP? Save time, contact us first. 888-648-8665 support@tektontools.com WARNING: WEAR IMPACT-RESISTANT PROTECTIVE EYEWEAR IN WORK AREA AT ALL TIMES.
PAGE 2
VISE SPECIFICATIONS #5409 - 8in. Swivel Bench Vise Jaw width Jaw opening Throat depth Swivel Pipe jaw capacity Weight Anvil size Mounting holes (3) 8 in. 6-3/8 in. 3-7/16 in. 360º 1-1/4 to 2-1/2 in. 40.2 lb. 3-3/4 in (square) 11/16 in.
PAGE 3
SETUP AND MAINTENANCE • Keep machined surfaces and all moving parts clean and free of dirt, chips, and foreign materials. • Use multipurpose grease to keep moving parts lubricated. • Routinely apply mineral oil to machined surfaces to prevent surface rust. MOUNTING VISE 1. Use included mounting template to identify desired vise mounting location. (Suggested placement shown in diagram below) 2. Mark and drill holes. Make certain the drilling path is clear of any hazards. 3.
PAGE 4
SAFETY INSTRUCTIONS WARNING: Misuse of vise can cause serious injury. Vise must be installed and used properly. Follow all instructions below. WHEN USING VISE ALWAYS make sure the workbench top is secure. ALWAYS use eye, face, and ear protection. ALWAYS keep moving parts lubricated with multipurpose grease. ALWAYS keep workpiece centered in jaws. Uneven clamping pressure across jaws could damage vise. DO NOT overtighten jaws or lockdowns, damage to vise or workpiece could result. TIGHTEN BY HAND ONLY.
