Data Sheet
Key Features
• Choose from one 195 W model and two 375 W models
• 195 W model has two 30 V, 3 A channels and one 5 V,
3 A channel
• 375 W models have two 30 V, 6 A channels or two
60 V, 3 A channels and one 5 V, 3 A channel
• All channels are independently controlled and are
isolated to power a wide range of test setups
• All channels have remote sensing so the programmed
voltage is accurately applied to the load
• Set and monitor output voltages with 0.03% basic
accuracy and 1 mV resolution
• Monitor load current with 0.1% basic accuracy and
1 mA resolution
• Low noise, linear regulation with <1 mV rms
ripple and noise
• Combine channels in series to output as high as 60 V
and in parallel with two or three channels to create
capacity as high as 15 A (2230G-30-6)
• Voltage and current outputs of three channels are
displayed simultaneously for immediate observation of
each output state
• USB, GPIB, and RS-232 interfaces and rear panel
connections for automated test convenience
2230G-30-3, 2230G-30-6, 2230G-60-3
High Power, 3-Channel Programmable Power Supplies
Datasheet
Applications
Series 2230G power supplies are ideal for testing:
• High power analog ICs
• Automotive circuits
• Telecom infrastructure circuits
• LED driver circuitry
The Series 2230G 3-channel programmable power
supplies provide up to 375 W of power in a space-saving
2U high, half-rack width enclosure to power automotive
circuits, LED drivers, power supplies, power ICs, and
other high-power circuits. The 2230G-30-3 offers 195 W
with two 30 V, 3 A channels and a 5 V, 3 A channel.
The 2230G-30-6 and the 2230-60-3 supplies output as
much as 375 W. The 2230G-30-6 provides two 30 V,
6 A channels, while the 2230G-60-3 has two 60 V, 3 A
channels. Both 375 W supplies have a 5 V, 3 A channel as
the third channel. These three supplies are linear power
supplies; thus, they are low noise supplies to have minimal
impact on a device-under-test (DUT). Each channel has a
rectangular output characteristic to enable obtaining the
full current at the maximum voltage so that the 2230G-30-
6 can supply 30 V to a 6 A load and the 2230G-60-3 can
supply 60 V to a 3 A load.
