Acquire the Sign
al
Acquire the Si
gnal
This section describes concepts of and procedures for setting up the oscilloscope to acquire the signal as you want it to.
Setting Up Analog Channels
Use front panel buttons and knobs to set up your instrument to acquire signals using the analog channels.
1. Connect the
TPP0250/TPP0500B/TPP1000 or VPI
probe to the input signal source.
2. Select the input channel by pushing the
front panel buttons.
NOTE. If you are using a probe that does not
supply probe encoding, set the attenuation
(probe factor) in the oscilloscope vertical
menu for the channel to match the probe.
3. Push Default Setup.
4. Push Autoset.
54 MDO3000 Series Oscilloscopes User Manual
