Acquire the Sign
al
Frequency
& Span
2. Push Center Fr
equency on the side menu
and use either the Multipurpose a knob or
the oscilloscope keypad to enter the desired
center frequ
ency. If you use the keypad,
you can also use the resulting side menu
choices to enter units.
Center
Frequency
(a)
2.24 GHz
3. Push Span and use either the Multip urpose
b knob or the keypad to enter the desired
span. If you
use the keypad, you can also
use the resulting side menu choices to enter
units.
Span
(b)
3.00 GHz
4. Push Start to set the lowest frequency to
capture.
Start
7.36 MHz
5. Push Stop to set the highest frequency to
capture.
Stop
3.74 GHz
6. Push To Center to move the frequency
identified by the reference marker to the
center frequency.
To Center
Reference Level
1. Push A
mpl to bring up the side menu for
adjusting RF amplitude settings.
MDO3000 Series Oscilloscopes User Manual 85
