Display Wavefor
morTraceData
Display Wavef
orm or Trace Data
This section contains concepts and procedures for displaying the acquired waveform or trace.
Adding and Removing a Waveform
1. To add or remove a w aveform from the
display, push the corresponding front
panel channel button or the D15-D0
button.
You can use the channel as a trigger
source whether or not it is displayed.
Setting the Display Style and Persistence
1. To set the display style, push Acquire.
2. Push Waveform Display.
Mode
Sample
Record
Length
10k
FastAc
q
Off
Delay
On
Off
Set Horiz.
Positi
on to
10%
Waveform
Displa
y
XY Disp
lay
On
