Analyze Wavefor
morTraceData
In this example
, two vertical cursors appear
on the selected waveform. As you turn
Multipurpose a, you move one cursor to the
right or left.
As you turn knob Multipurpose
b, you move the other cursor.
2. With cursors on, push Select.
This turns the cursor linking on and off.
If linking
is on, turning M ultipurpose a
moves the two cursors together. Turning
Multipurpose b adjusts the time between
the cursor
s.
3. Push Fine to toggle between a coarse and a
fine adjustment for the Multipurpo se a and
Multipur
pose b knobs.
Pushing Fine also changes the sensitivity of
other k nobs as well.
4. Push and hold Cursors to display the cursor
menu.
5. Push Cursors on the lower menu to set the
cursors to Screen.
In sc re
en mode, two horizontal bars and two
vertical bars span the graticule.
Cursors
Wavefo
rm
Screen
Source
Selec
ted
Waveform
Bars
Horizontal
Vertical
Linked
On
Off
Bring
Cursors
On Screen
Cursor
Units
6. Turn
Multipurpose a and Multipurpose b
to move the pair of horizontal cursors.
