Compliance info
rmation
Australia / New Zealand Declaration of Conformity – EMC
Complies with the EMC provision of the Radiocommunications Act per the following standard, in accordance with ACMA:
CISPR 11:2003. Radiated and Conducted Emissions, Group 1, Class A , in a ccordance with EN 61326-1:2006 and
EN 61326-2-1:2006.
Australia / New Zealand contact.
Baker & McKenzie
Level 27, AMP Centre
50 Bridge St
reet
Sydney NSW 2000, Australia
Russian Federation
This product is approved by the Russian government to carry the GOST mark.
Safety compliance
This section lists the safety standards with which the product complies and other safety compliance information.
EU decla
ration of conformity – low voltage
Compliance was demonstrated to the following specification as listed in the Official Journal of the European Union:
Low Voltage Directive 2014/35/EU.
EN 61010-1. Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use – Part
1: General Requirements.
EN 61010-2-030. Safety Requirements for Electrical Equipment for M easurement, Control, and Laboratory Use – P art
2-030: Particular requirements for testing and measuring circuits.
U.S. nationally recognized testing laboratory listing
UL 61010-1. Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use – Part
1: Ge
neral Requirements.
UL 6
1010-2-030. Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use – Part
2-030: Particular requirements for testing and measuring circuits.
Canadian certifi cation
CAN/CSA-C22.2 N o. 61010-1. Safety Requirements for Electrical E quipment for Measurement, Control, and Laboratory
Use – Part 1: General Requirements.
CAN/CSA-C22.2 No. 61010-2-030. Safety R equirements for Electrical Equipment for Measurement, Control, and
Laboratory Use – Part 2-030: Particular requirements for testing and measuring circuits.
MDO3000 Series Oscilloscopes User Manual xi
