Analyze Wavefor
morTraceData
R1
3. Push Vertical on the side menu and use
the multipurpose knobs to adjust the vertical
settings of th
e reference waveform or trace.
Vertical
0.00 div
100 mV/div
4. Push Horizontal on the side menu and
use the multipurpose knobs to adjust
the horizont
al settings of the reference
waveform or trace.
Horizontal
0.00 s
4.00 s/div
5. Push Edit Label and use the resulting
menus to defi
ne labels to display with the
reference waveforms and traces.
Edit Labels
6. Pus Ref Det
ails to read information
about the selected reference. Use this
to determine whether the reference is an
analog wa
veform or an RF trace.
Ref Details
7. Push Save to File to store reference
informa
tion in external storage.
Save to
File
Quick T
ips
Selecting and Displaying Reference Waveforms. You can display all the reference waveforms at the s ame time.
Push the appropriate screen button to select a particular reference waveform.
Removing Reference Waveforms from the Display. To remove a reference waveform from the display, push R on the
front panel to access the lower menu. Then push the associated lower menu to turn it off.
Scaling and Positioning a Reference Waveform. You can position and scale a reference w aveform independently
from all other displayed waveforms. Select the reference waveform and then adjust it with a multipurpose knob. You can
do this whether acquisition is running or not.
If a reference waveform is selected, scaling and repositioning of the reference w aveform operates the same way
whether zoom is turned on or off.
Saving 10 M Reference Waveforms. 10 M reference waveforms are volatile and not saved when the oscilloscope
power is turned off. To keep these waveforms, save them to external storage.
