Analyze Wavefor
morTraceData
3. Investigate your waveform by moving
from search mark to search m ark. Use
the next ( )or
previous ()arrow
button to jump from one marked location
to another, without adjusting any other
controls.
4. Deleteamar
k. Push the next ( )or
previous () arrow button to jump to the
mark you want to clear. To remove the
current, ce
nter-positioned mark, push
Set/Clear. It works on both manually
and automatically created marks.
To automatically set and clear (delete) search marks:
1. Push Sear
ch.
2. S elect the search type desired from the
lower me
nu.
Search
Off
Search
Type
Edge
Source
1
Slope
Threshold
0.00V
The sear
ch menu is similar to the trigger
menu.
3. From the side menu, turn on the search
function.
If des
ired, go to the s econd page of the
side menu and turn on the search mark
table. The search mark table shows a
time-
stamped listing of each event.
152 MDO3000 Series Oscilloscopes User Manual
