Analyze Wavefor
morTraceData
3. Push Analysis
.
Applica-
tion
Analysis
None
4. Use the side m
enu buttons to select the
desired analysis function.
Choose among:
- Power qual
ity
- Switching loss
- Harmonics
- Ripple
- Modulation
- Safe operating a rea
-Deskew
See the MDO3PWR, DP O3PWR and
DPO4PWR Power Analysis Modules User
Manual fo
r more information.
MDO3000 Series Oscilloscopes User Manual 161
