Save and Recall I
nformation
2. Push R1, R2, RI
or R4.
(R1) |(On) (R2) |(Off) (R3) |(Off) (R4) |(Off)
If you push the side menu Ref Details,you
can read wheth
er the reference holds analog
waveform or RF trace information.
Removing a reference waveform from the display. To remove a reference waveform from the display:
1. Push Ref R.
2. Push R1, R2, RI or R4 on the lower menu
to remove t
he reference waveform or trace
from the display.
(R1) |(On) (R2) |(Off) (R3) |(Off) (R4) |(Off)
The refer
ence waveform is still in nonvolatile
memory and can be displayed again with
another push of the button.
NOTE. 10
M reference waveforms are volatile
and not saved w hen the oscilloscope power is
turned off. To keep these waveforms, save them
to exter
nal storage.
Saving
and Recalling Setups
Setup information includes acquisition information, such as vertical, horizontal, trigger, cursor, and measurement information.
It does not include communications information, such as GP IB addresses. To save the setup information:
1. Push Save / Recall Menu.
2. Push Save Setup or Recall Setup on the
lower menu.
Save
Screen
Save
Waveform
Save
Setup
Recall
Waveform
Recall
Setup
Assign
Save|to
Setup
File
Utilities
