Save and Recall I
nformation
7. Turn Multipurp
ose a to scroll through the
list of letters, numbers, and other characters
to find the first character in the name that
you want to ent
er.
If you are using a USB keyboard, use
the arrow keys to position the insertion
point and typ
e in the printer name. (See
page 35, Connecting a USB Keyboard to
Your Oscilloscope.)
NOTE. There i
s a single set of SMTP server
settings saved for both the e-mail printer and
for Act on Event e-mail notification (Test >
Applicatio
n > Act on Event > Actions >
E-mail Notification > Configure E-mail). If you
modify the SMTP settings in one of these two
locations
, they will be similarly modified in the
other location.
ABCDEFGHIJKLMNOPQRSTUVWXYZ
abcdefghijklmnopqrstuvwxyz
0123456789_=+-!@#$%^&*()[]{}<>/~'”\|:,.?
8. Push Select or Enter Character to let the
oscilloscope know that you have picked the
proper ch
aracter to use.
You can use the lower menu buttons to edit
the name
, as needed.
Enter
Charact
er
Back
Space
Delete
Clear
9. Continue scrolling and pushing Select until
you hav
e entered all the desired characters.
10. Push the down arrow key to move the
character cursor down to more rows to fill
out.
Add
Printer
11. Turn the Multipurpose a knob and push
Select or Enter Character as often a s
need
ed to enter the name.
12. If desired, push the down arrow key to move
the
character cursor down to added rows.
OK Accept
13. Turn Multipurpose a and push Select or
Enter Character as often as needed to enter
the name.
