Save and Recall I
nformation
4. Push TekSecure Erase Mem ory.
Utility
Page
Security
TekSecure
Erase
Memory
5. Push OK Erase Setup and Ref Memory
on the side menu.
This erases
data in the oscilloscope’s
reference waveform and setup memory
locations.
OK
Erase
Setup
&Ref
Memory
To cancel the procedure, push Menu Off.
MDO3000 Series Oscilloscopes User Manual 181
