Save and Recall I
nformation
6. P ower off the oscilloscope, and then power
it back on to complete the process.
To use TekSecure, with the MDO3SEC application module installed :
1. Push Utility.
2. Push Utility Page.
Utility
Page
3. Turn the Multipur pose a knob and select
Security.
Security
182 MDO3000 Series Oscilloscopes User Manual
