This manual describes the installation and operation of the following oscilloscopes:
Model MDO3104 MDO3102 MDO3054 MDO3052 MDO3034
Bandwidth
1GHz 1GHz
500 MHz 500 MHz 350 MHz
Analog Channels
424 2 4
Digital Channels
16 16 16 16 16
RF Channels
111 1 1
Sample R ate
(1 ch)
5 GS/s 5 GS/s 2.5 GS/s 2.5 GS/s 2.5 GS/s
Sample R ate
(2 ch)
5 GS/s 5 GS/s 2.5 GS/s 2.5 GS/s 2.5 GS/s
Sample R ate
(4 ch)
2.5 GS/s N/A 2.5 GS/s N/A 2.5 GS/s
Record Length
(1 ch)
10 M 10 M 10 M 10 M 10 M
Record Length
(2 ch)
10 M 10 M 10 M 10 M 10 M
Record Length
(4 ch)
10 M
N/A
10 M
N/A
10 M
RF Frequency Range
9kHz-1GHz 9kHz-1GHz
9 kHz - 500 MHz 9 kHz - 500 MHz 9 kHz - 350 MHz
AFG Outputs
111 1 1
Model MDO3032 MDO3024 MDO3022 MDO3014 MDO3012
Bandwidth 350 MHz 200 MHz 200 MHz 100 MHz 100 MHz
Analog Channels
2424 2
Digital Channels
16 16 16 16 16
RF Channels
1111 1
Sample R ate
(1 ch)
2.5 GS/s 2.5 GS/s 2,5 GS/s 2.5 GS/s 2.5 GS/s
Sample R ate
(2 ch)
2.5 GS/s 2.5 GS/s 2.5 GS/s 2.5 GS/s 2.5 GS/s
Sample R ate
(4 ch)
N/A 2.5 GS/s N/A 2.5 GS/s N/A
Record Length
(1 ch)
10 M 10 M 10 M 10 M 10 M
Record Length
(2 ch)
10 M 10 M 10 M 10 M 10 M
