Preface
Model MDO3032 MDO3024 MDO3022 MDO3014 MDO3012
Record Length
(4 ch)
N/A
10 M
N/A
10 M
N/A
RF Frequency Range 9 kHz - 350 MHz 9 kHz - 200 MHz 9 kHz - 200 MHz 9 kHz - 100 MHz 9 kHz - 100 MHz
AFG Outputs
1111 1
Key Feature
s
MDO3000 Mixed Domain Oscilloscopes are 6-in-1 integrated oscilloscopes, offering a built-in spectrum analyzer, arbitrary
function generator, logic analyzer, protocol analyzer, digital voltmeter and frequency counter. Key features include:
A dedicated RF input channel for frequency domain measurements
Four or two analog channels for time domain measurements
Models are available with bandwidths from 100 MHz to 1 GHz
Sample rates of 2.5 GS/s on all analog channels (5 GS/s on 1 or 2 channels for the MDO3104 or MDO3102)
10 M points record length on all channels
Maximum waveform capture rate: >280,000 waveforms/second with FastAcq. >50,000 waveforms/second with
normal operation.
Advanced triggering and analysis: ARINC429, I
2
C, SPI, USB 2.0, CAN, CAN FD, LIN, FlexRay, RS-232, RS-422,
RS-485, U ART, I
2
S, Left Justified (LJ), Right Justified (RJ), T DM, MIL-STD-1553 (with the appropriate application
module), and Parallel
Power analysis, and limit and mask testing application modules (optional)
Arbitrary function generator and 16 digital c hannels (optional)
Digital voltmeter free with product registration
Conventions Used in This Manual
The following icons are used throughout this manual.
Sequence Step
Fron
t panel power
Connect power
Netw
ork
USB
xvi MDO3000 Series Oscilloscopes User Manual
