Appendix B: TPP0
250, TPP0500B and TPP1000: 250 MHz, 500 MHz and 1 GHz 10X Passive P robes Information
Appendix B: TPP0250, TPP0500B and TPP1000: 250 MHz,
500 MHz and 1 GHz 10X Passive Probes Information
Operating In
formation
The TPP0250, TPP0500B and TPP1000 10X Passive Probes are compact passive probes with 10X attenuation that are
designed for use with Tektronix MDO3000 Series oscilloscopes.
The probes have no user- or Tektronix-serviceable parts.
Connecting the Probe to the Oscilloscope
Connect the probe as shown in the illustrations below.
Compensating the Probe with MDO3000 Series Oscilloscopes
For information on compensating the probe, refer to the related section earlier in this manual.
(See page 11, Compensating a TPP0250, TPP0500B or TPP1000 Passive Voltage Probe.)
Stan
dard Accessories
The standard accessories included with the probe are shown below.
WARNING. To avoid electric shock when using the probe or accessories, keep fingers behind the finger guard of probe
body and accessories.
To reduce risk of shock, when using the probe on floating m easurements, ensure the reference lead accessories are fully
mated before connecting the probe to the circuit under test.
198 MDO3000 Series Oscilloscopes User Manual
