Appendix C : P631
6 General-Purpose Logic P robe Information
Typical Application
1. Use the P6316 probe to view digital signals on a system bus.
2. Use an analog probe, such as the TPP0250, TPP0500B or TPP1000 passive probe, to view analog waveform information.
Probe le
ad sets:
Probe Group 1 Group 2
Black probe 0 8
Brown probe 1 9
Red pro
be
210
Orang
e probe
311
Yellow probe 4 12
Green probe
5
13
Blue probe 6 14
Viol
et probe
7
15
