User Manual
Table Of Contents
- toc
- Important safety information
- Compliance information
- Preface
- Installation
- Before Installation
- Operating Considerations
- Connecting Probes
- Securing the Oscilloscope
- Powering on the Oscilloscope
- Powering off the Oscilloscope
- Functional Check
- Compensating a TPP0250, TPP0500B or TPP1000 Passive Voltage Prob
- Compensating a non-TPP0250, non-TPP0500B or non-TPP1000 Passive
- Application Module Free Trial
- Installing an Application Module
- Upgrading Bandwidth
- Changing the Language of the User Interface or Keyboard
- Changing the Date and Time
- Signal Path Compensation
- Upgrading Firmware
- Connecting Your Oscilloscope to a Computer
- Connecting a USB Keyboard to Your Oscilloscope
- Get Acquainted with the Instrument
- Acquire the Signal
- Setting Up Analog Channels
- Using the Default Setup
- Using Autoset
- Acquisition Concepts
- Using FastAcq
- How the Analog Acquisition Modes Work
- Changing the Acquisition Mode, Record Length, and Delay Time
- Using Roll Mode
- Act on Event
- Setting Up a Serial or Parallel Bus
- Setting Up Digital Channels
- When and Why to Turn On MagniVu
- Using MagniVu
- Setting Up the RF Inputs
- Trigger Setup
- Display Waveform or Trace Data
- Adding and Removing a Waveform
- Setting the Display Style and Persistence
- Setting Waveform Intensity
- Scaling and Positioning a Waveform
- Setting Input Parameters
- Positioning and Labeling Bus Signals
- Positioning, Scaling, and Grouping Digital Channels
- Viewing Digital Channels
- Annotating the Screen
- Viewing the Trigger Frequency
- Displaying the Frequency Domain Menu
- Analyze Waveform or Trace Data
- Using Markers in the Frequency Domain
- Taking Automatic Measurements in the Time Domain
- Selecting Automatic Measurements in the Time Domain
- Customizing an Automatic Measurement in the Time Domain
- Taking Automatic Measurements in the Frequency Domain
- Taking Digital Voltmeter Measurements
- Taking Manual Measurements with Cursors
- Setting Up a Histogram
- Using Math Waveforms
- Using FFT
- Using Advanced Math
- Using Spectrum Math
- Using Reference Waveforms and Traces
- Using Wave Inspector to Manage Long Record Length Waveforms
- Auto-magnify
- Limit and Mask Testing
- Making Video Tests
- Making Automated Power Measurements
- Save and Recall Information
- Use the Arbitrary Function Generator
- Use the Application Modules
- Appendix A: Warranted Specifications
- Appendix B: TPP0250, TPP0500B and TPP1000: 250€MHz, 500€MHz and
- Appendix C: P6316 General-Purpose Logic Probe Information
- Appendix D: OpenSSL License
Installation
Installation
Before Installation
Unpack the oscilloscope and check that you r eceived all items listed as standard accessories. The following pages list
recommended accessories and probes, instrument options, and upgrades. Check the Tektronix Web site (www.tektronix.com)
for the most current information.
Standard accessories
Accessory Description
Tektronix part
number
MDO3000 Installation and Safety Manual General installation and safety information
071-3249-XX
MDO3000 Series Oscilloscopes
Documentation Browser CD
Electronic versions of or links to documents,
including the User Manual, Programmer
Manual and the Technical Reference.
Tektronix OpenChoice Desktop CD
Productivity, analysis, and documentation
software
063-4526-XX
Calibration certificate documenting
traceability to national metrology institute(s),
and ISO9001 quality system registration.
––
French (Option L1)
335-3264-XX
Italian (Option L2)
335-3265-XX
German (Option L3)
335-3266-XX
Spanish (Option L4)
335-3267-XX
Japanese (Option L5)
335-3268-XX
Portuguese (Option L6)
335-3269-XX
Simplified Chinese (Option L7)
335-3270-XX
Traditional Chinese (Option L8)
335-3271-XX
Korean (Option L9)
335-3272-XX
Front Panel Overlay
Russian (Option L10)
335-3273-XX
For 100 and 200 MHz models, one 250 MHz,
10X passive probe per channel
Two TPP0250 for the MDO3012/22 and
four TPP0250 for the MDO 3014/24
TPP0250
For 350 and 500 MHz models, one 500 MHz,
10X passive probe per channel
Two TPP0500B for the MDO3032/52 and
four TPP0500B for the MDO3034/54
TPP0500B
Probes
For 1 GHz models, one 1 GHz, 10X passive
probe per channel
Two TPP1000 for the MDO3102 and four
TPP1000 for the MDO3104
TPP1000
Adapter
NMaletoBNCFemale
103-0473-XX
MDO3000 Series Oscilloscopes User Manual 1
