Appendix C: P631
6 General-Purpose Logic P robe Information
Accessories
The following standard a ccessories ship with the probe and are s hown in the illustration that follows.
Item Description Quantity Part n um ber
1 8-channel leadset 2 196-3508-XX
2 Micro grabber clip
2kitsof10each
020-2896-XX
3 Probe tip
2 kits of 5 each
020-2897-XX
—
Instructions (English, Japanese, & Simplified
Chinese languages)
1 each 071-2345-XX
1
Instructions are included with the probe, but not in the accessory kit.
The instructions can be downloaded at www.tektronix.com/manuals.
