Appendix C: P631
6 General-Purpose Logic P robe Information
Do not Operate Without Covers. Do not touch exposed connections and components when power is present.
Avoid Exposed Circuitry. Do not touch exposed connections and components when power is present.
Do Not Operate With Suspected Failures. If you suspect there is damage to this product, have it inspected by
qualified serv
ice personnel.
Do Not Operate in Wet/Damp Conditions. Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
Safety Terms and Symbols in This Manual.
These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result in injury or loss of l ife.
CAUTION. Caution statements identify c onditions or practices that could r esult in damage to this product or other property.
Symbols on the Product. This symbol may appear on the product:
210 MDO3000 Series Oscilloscopes User Manual
