Installation
Optional accessories (cont.)
Accessory Description
Tektronix part
number
MDO3000 Series Application Module
Installation Instructions
Describes how to install application modules
on your oscilloscope
071-3250-XX
English (Option L0)
071-2631-XX
French (Option L1)
077-0235-XX
Italian (Option L2)
077-0236-XX
German (Option L3)
077-0237-XX
Spanish (Option L4)
077-0238-XX
Japanese (Option L5)
077-0239-XX
Portuguese (Option L6)
077-0240-XX
Simplified Chinese (Option L7)
077-0241-XX
Traditional Chinese (Option L8)
077-0242-XX
Korean (Option L9)
077-0243-XX
MDO3PWR, DPO3PWR and DPO4PWR
Power Measurement Module User Manual
Russian (Option L10)
077-0244-XX
MDO3000 Series Oscilloscopes
Declassification and Security Instructions
Describes how to sanitize or remove memory
devices from the Tektronix MDO3000 Series
oscilloscopes
077-0980-XX
The MDO3000 Series oscilloscopes support a multitude of optional probes. (See page 7, Connecting Probes.) Visit the
Oscilloscope Probe and Accessory Selector Tool on the Tektronix Web site (www.tektronix.com/probes) for the most up
to date information.
Operating Considerations
MDO3000 Series O
scilloscopes
Mains Input Voltage: 100 V to 240 V ±10%
Mains Input Power Frequency:
50/60 Hz at 100 V to 240 V
400 Hz ± 10% at 100 to 132 V
Weight: 4.2 kg (9.2 lbs), standalone instrument
Height, including feet but not handle:
203.2 mm (8 in)
Width, 416.6 mm (16.4 in)
Depth, 147.4 mm (5.8 in)
Clearance: 51 mm (2 in)
MDO3000 Series
Temperature
:
Operating: –10 °C to +55 °C (+14 °F to +131 °F)
Nonoperating: –40 °C to +71 °C (–40 °F to +159 °F)
MDO3000 Series Oscilloscopes User Manual 5
