Get Acquainted w
ith the Instrument
4. B1 or B2.Pushtodefine and display a
bus if you have the appropriate module
application k
eys.
MDO3AERO supp
orts ARINC429
and MIL-STD-1553 buses.
MDO3AUDIO supports I
2
S, Left
Justified (LJ), Right Justified (RJ),
and TDM buses
.
MDO3AUTO su
pports CAN, CAN
FD, and LIN buses.
MDO3EMBD supports I
2
C and SPI
buses.
MDO3COMP supports RS-232,
RS-422, RS
-485, and UART buses.
MDO3FLEX s
upports FlexRay buses.
MDO3USB s
upports USB 2.0 buses.
Also, push the B1 or B2 button to display
or remov
e the corresponding bus from
the display.
5. R. Push to manage reference waveforms
and traces, including the display or
remova
l of each reference w aveform or
trace from the display.
6. M. Push to manage the math waveform
or trace, including the display or removal
of the
math waveform or trace from the
display.
40 MDO3000 Series Oscilloscopes User Manual
