Acquire the Sign
al
Act on Event
Tell the oscilloscope to perform a defined action after a defined event has occurred. The event can be a trigger or a certain
number of acquisitions. T he action can be to:
Stop acquisitions
Save a waveform or a screen image to a file
Print
Send a pulse out the AUX OUT port
Generate a remote interface SRQ
Send an e-mail notification
Display a message on the oscilloscope display
1. Push Test.
2. Push Application on the lower-menu.
Application
Act on
Event
Event
Acquisition
Action Repeat
Off
3. Turn Multipurpo se a to select Act on Event
4. Push Event on the lower menu.
This brings up the event type side menu.
Sele
ct the desired event type.
MDO3000 Series Oscilloscopes User Manual 65
