Acquire the Sign
al
5. O ptionally, push B1 Label to edit the label for
the bus. (See page 55, Labeling Channels
and Buses.)
Bus B1
Parallel
Define
Inputs
Thresholds B1 Label
Parallel
Bus
Display
Event
Table
6. Push Bus Display and use the side menu
to define how
to display the parallel or serial
bus.
Bus
Depending on the bus, use the side menu or
the knobs t
o set the number format.
Bus and
Wave-
forms
Hex
Binary
ASCII
7. Push Event Table and select On to disp lay a
list of b
us packets with timestamps.
Event
Table
On Off
Save
Event
Table
For a clocked parallel bus, the table lists the value of the bus at each clock edge. For an unclocked parallel bus, the table
lists the value of the bus whenever any one of its bits changes.
The Ev
ent Table lists bytes, words, or packets, depending on the bus type.
(See page 80, Event Table .)
8. Push
Save E vent Table to save the ev ent
table data in a .csv (spreadsheet) format on
the currently selected storage device.
70 MDO3000 Series Oscilloscopes User Manual
