2.21.2 PD_RequestDataObject_Fixed_Variable_GiveBack
Used as data for PD_RequestPacket. This packet template has same fields as
PD_RequestDataObject_Fixed_Variable_NoGiveBack packet template, but default value for
GiveBackFlag field is 1.
2.21.3 PD_RequestDataObject_Battery_NoGiveBack
Used as data for PD_RequestPacket. Available fields for this packet template are:
Field Name
Description
MaxOperatingPower_250mWUnits
Default: 0
OperatingPower_250mWUnits
Default: 0
Rsvd1
Default: 0
UnchunkedExtMsgSupported
Default: 0
Rev3.0 only
NoUsbSuspend
Default: 0
UsbCommunicationsCapable
Default: 0
CapabilityMismatch
Default: 0
GiveBackFlag
Default: 0
ObjectPosition
Default: 1
Rsvd2
Default: 0
2.21.4 PD_RequestDataObject_Battery_GiveBack
Used as data for PD_RequestPacket. This packet template has same fields as
PD_RequestDataObject_Battery_NoGiveBack packet template, but default value for GiveBackFlag field
is 1.
2.22 PD_BISTCarrierModeMessage
PD_BISTCarrierModeMessage packet template contains all the fields of PD_ControlMessage but
default value for MessageType is 3 and default value for NumberOfDataObjects field is 1.
Following are additional data fields for PD_BISTCarrierModeMessage packet template:
Field Name
Description
Reserved
Default: 0
BISTRequestType
Default: BIST_REQUEST_CARRIER_MODE
2.23 PD_BISTTestDataMessage
PD_BISTTestDataMessage packet template contains all the fields of PD_ControlMessage but
default value for MessageType is 3 and default value for NumberOfDataObjects field is 7.
Following are additional data fields for PD_BISTTestDataMessage packet template:
Field Name
Description
Reserved
Default: 0
BISTRequestType
Default: BIST_REQUEST_TEST_DATA
TestData
Default: {AA AA AA AA AA AA AA AA AA AA AA AA AA AA
AA AA AA AA AA AA AA AA AA AA}
2.24 PD_BatteryStatusMsg
Applied to Rev3.0. PD_BatteryStatusMsg packet template contains all the fields of
PD_ControlMessage but default value for MessageType is 5 and default value for
