29
HotSwappableBattery
Default: 0x00
2.46 PD_GetBatteryCapMsg
Applied to Rev3.0. PD_GetBatteryCapMsg packet template contains all the fields of
PD_ExtMsgHeaders but the default value of MessageType field is 3 and the default value of
DataSize field is 0x01. Following are the additional fields(fields of PD_GetBatteryCapDataBlock
packet template) for this packet template:
Field Name
Description
BatteryCapRef
Default: 0x00
2.47 PD_GetBatteryStatusMsg
Applied to Rev3.0. PD_GetBatteryStatusMsg packet template contains all the fields of
PD_ExtMsgHeaders but the default value of MessageType field is 4 and the default value of
DataSize field is 0x01. Following are the additional fields(fields of
PD_GetBatteryStatusDataBlock packet template) for this packet template:
Field Name
Description
BatteryStatusRef
Default: 0x00
2.48 PD_BatteryCapabilitiesMsg
Applied to Rev3.0. PD_BatteryCapabilitiesMsg packet template contains all the fields of
PD_ExtMsgHeaders but the default value of MessageType field is 5 and the default value of
DataSize field is 0x09. Following are the additional fields(fields of PD_BatteryCapDataBlock
packet template) for this packet template:
Field Name
Description
VendorId
Default: 0x00
ProductId
Default: 0x00
DesignCapacity
Default: 0x00
LastFullChargeCapacity
Default: 0x00
BatteryType
Default: 0x00
2.49 PD_GetManufacturerInfoMsg
Applied to Rev3.0. PD_GetManufacturerInfoMsg packet template contains all the fields of
PD_ExtMsgHeaders but the default value of MessageType field is 6 and the default value of
DataSize field is 0x02. Following are the additional fields(fields of
PD_GetManufacturerInfoDataBlock packet template) for this packet template:
Field Name
Description
Target
Default: 0x00
ManufacturerInfoRef
Default: 0x00
2.50 PD_ManufacturerInfoMsg
Applied to Rev3.0. PD_ManufacturerInfoMsg packet template contains all the fields of
PD_ExtMsgHeaders but the default value of MessageType field is 7 and the default value of
DataSize field is 0x04. Following are the additional fields for this packet template:
