Pass Through cable or not.
Possible values:
PD_FALSE(default),
PD_TRUE
PDWorkingRevision
Sets the Power Delivery working revision. It should be set only once in the
target Exerciser Script. Its recommended to change this setting using
PD_SetWorkingRevision high-level function.
Possible values:
PD_SPEC_REVISION_2(Default)
PD_SPEC_REVISION_3
UnchunkedSupport
Indicates whether to support sending un-chunked messages or not.
Possible values:
PD_FALSE,
PD_TRUE (default)
StructuredVDMVersion
Indicates the VDM version of structured VDM messages. If the value is
PD_INVALID_VALUE then the Exerciser puts the proper value for
structured VDM version according to current operational Power Delivery
Revision.
Possible values:
PD_INVALID_VALUE(default)
Or any user defined value.
List of $PdTimers fields(for detailed description refer to Power Delivery Specification):
Field Name
Description
tTypeCSinkWaitCap
Default: 620000 us
tTypeCSendSourceCap
Default: 150000 us
tPSTransition
Default: 550000 us
tPSSourceOff
Default: 900000 us
tPSSourceOn
Default: 450000 us
tSrcTransition
Default: 30000 us
tDiscoverIdentity
Default: 45000 us
tSafe0V
Default: 650000 us
tSafe5V
Default: 275000 us
tPSHardResetMin
Default: 25000 us
tPSHardResetMax
Default: 35000 us
tPSHardReset
Default: 30000 us
tSrcRecoverMin
Default: 660000 us
tSrcRecoverMax
Default: 1000000 us
tSrcRecover
Default: 1000000 us
tReceive
Default: 1100 us
tVCONNStable
Default: 50000 us
tVCONNSourceOff
Default: 25000 us
tVCONNSourceOn
Default: 100000 us
tSenderResponse
Default: 30000 us
tBISTContMode
Default: 60000 us
tVDMBusy
Default: 50000 us
tVDMWaitModeEntry
Default: 50000 us
tVDMWaitModeExit
Default: 50000 us
tSwapSourceStart
Default: 20000 us
tDRP
Default: 80000 us
dcSRC_DRP
Default: 50(time percent)
tCCDebounce
Default: 150000 us
tCCDebounceMin
Default: 100000 us
tCCDebounceMax
Default: 200000 us
tDRPTry
Default: 150000 us
tDRPTryMin
Default: 75000 us
tDRPTryMax
Default: 150000 us
tDRPTryWait
Default: 600000 us
tDRPTryWaitMin
Default: 400000 us
tDRPTryWaitMax
Default: 800000 us
tPDDebounce
Default: 15000 us
